ANNEX E

           Naming rules, data structures and related processes used in the pilot
           project






           E.1 NAMING                                         TABLE E-1: Data base format definition for team/
                                                              device assignment list
           E.1.1 General
           Element names shown in bold face are functional names   ELEMENT                     TYPE
           which shall be used consistently throughout all relevant   Team ID                  Varchar(128)
           documents. They may also have abbreviations used for   Device ID                    Varchar(64)
           brevity but only in the current clause of this document.
                                                               Start time and date of assignment  datetime
           E.1.2 Teams                                         End time and date of assignment  datetime
           Each team shall be given a unique Team ID (TID), made
           of alphanumeric characters. The TN can be freely cho-  The end time can be NULL indicating that the assign-
           sen but it shall not be changed over time.         ment is ongoing.

           E.1.3 Devices                                      E.3 NOTIFICATION SMS
           The Device ID (DID) is composed of the device’s role
           and index (e.g. SP1, FP2, and OP), underscore (‘_’) and   E.3.1 Transfer and data handling process
           the last 6 digits of the device’s IMEI.            The Notification SMS (NSMS) (sent to the A and B par-
             On log sheets, an abbreviated name using only the   ty) contain information about the DFS transaction. This
           device’s role is used. The full DID can be looked up by   information is used to complement the overall informa-
           the respective entry in the device/team assignment   tion.
           data (see below).                                  The steps of this process are:
             The IMEI is the identifier displayed if the code *#06#   •  NSMS arrive at respective devices
           is entered in the Phone Dial window.               •  The SMS backup process (see SMS Backup & restore
             In case of dual-SIM devices, they may have 2 IMEI. In
           that case, the IMEI for the first SIM position is used for   app) sends, when invoked, an e-mail with an XML
                                                                 file attachment to a specific location. This XML file
           the DID. Usually this is the first IMEI displayed for *#06#   contains a copy of all SMS which were stored on the
           (to be verified).                                     device at the time of invocation.
             Example for a full DID: SP1_123456
             On log sheets, Device Role Aliases can be used in-  •  The attachment is processed by importing it into the
           stead of the short role names. The following aliases are   project data base.
           defined:                                           The NSMS do not contain information about the devic-
             SP Full Capability                               es involved. This information must therefore be added
                                                              during the overall process of NSMS collection.
             FP Low Capability
                                                                 This is done using the following definition and pro-
                                                              cess:
           E.2 TEAM/DEVICE ASSIGNMENT LIST
                                                              •  The set-up of SMS backup allows to configure the
           A list is kept which records the assignment of devices   Subject. This Subject shall contain the DID of the re-
           to teams. As this assignment may change over time, the   spective device.
           respective time window is also recorded.           •  For import, the DID shall be added to the respective
             The list has the following elements:
                                                                 data items.
                                                              •  As each backup file is a snapshot of all SMS on the
                                                                 device, subsequent executions will produce dupli-
                                                                 cates  of  NSMS.  The  data  structure/import  process
                                                                 must have provisions to handle these duplicates.
