E.3.2 Notification SMS data table structure          The remaining orphans are again sorted into catego-
           TABLE E-2: Notification SMS data table structure   ries:
           ELEMENT                  TYPE                      –  A or B side SMS which have matching DFS transac-
                                                                tions. This indicates transactions where such SMS are
           Device ID                Varchar(64)
                                                                missing and shall be notified along accordingly.
           Import date and time     datetime
                                                              –  A or B side SMS which have no matching DFS trans-
           SMS content              Mirroring of XML structure
                                                                action. An investigation shall be conducted to clarify
                                                                the circumstances.
           E.3.3 Assignment of primary test data and SMS
           Each successful DFS transaction is assumed to produce   E.3.4 Storage and deletion aspects of SMS on devices
           a set of primary data (timestamp information according   The process of SMS back-up is based on periodic copies
           to the definitions elsewhere in the present document)   of all SMS on a particular device.
           and two confirmation SMS on the A and B device, re-  In the course of the test campaign, locally stored
           spectively.                                        SMSD will accumulate unless they are deleted. Dele-
           By processing SMS back-up copies uploaded to the   tion procedures carry the risk of unwanted deletion of
           data base, these SMS are assigned. There are two basic   meaningful data. A hard cause to delete SMS would be
           types (A side and B side SMS). There can be other SMS   capacity issue. Unless this is given, it is assumed to be
           on the device. Therefore, the classification and assign-  better to handle SMS duplicates — which is technically
           ment process has the following stages:             quite simple in data processing — than to run a deletion
           i)  Identify if a SMS is of type A-side, B-side or other.  process.
                                                              In case a deletion process is required after all, it is per-
           ii)  If A-side, attempt to find the matching B side SMS   formed along the following process:
             from another device.
                                                              i)  There are regular device maintenance cycles (e.g.
           iii) If B-side, attempt to find the matching A-side SMS   once per week) where all devices used in the test
             (actually steps 2 and 3 are symmetrical).           campaign are participating.
           iv) Attempt to find the matching primary transaction   ii)  From processing of previously uploaded data, a ref-
             for the A-side and B-side SMS, respectively, using   erence  point  in  time  for  DFS  confirmation  SMS  is
             device/team allocation and timestamp                calculated (SMS-RP, type time/date). It is assumed
           Ideally, the process assigns all A-side and B-side SMS.   that up to this RT, all uploaded SMS are checked
           It is expected that “orphans” exist which do not have a   and assigned (see Assignment of primary test data
           counterpart. For such orphans, the first step is to check   and SMS) and that any hints on missing SMS (de-
           if SMS exist on devices which have not been covered by   tected as missing in uploaded data, to be checked
           the backup process. If this check finds previously miss-  for on devices) are clarified.
           ing SMS, they shall be processed.                  iii) In the maintenance process, all locally stored SMS
                                                                 older than the SMS-RP are deleted.
