–  Location Log Sheet: Initial, intermediate and final   In case of fully automated data acquisition, typical
             checks on device set-up and status.              time resolution is 1msec while typical phase durations
                                                              are at least a couple of 100msec or longer.
           –  Data Log Sheet (P2P Transfer): Acquisition of results   The other extreme is entirely manual time-taking
             for service tests.
                                                              where time resolutions are much longer, typically 1 s
           –  Event Log Sheet: capture of unusual conditions or   or even more considering that times have to be read
             events during tests.                             from a display which by itself may contain additional
           An example of an actual campaign log used in the pilot   delay. Even in the case of semi-automatic data acqui-
           campaign done in Ghana is shown in Appendix I      sition where some kind of stopwatch with high reso-
                                                              lution is used, human reaction time and its jitter will
           6.5  Handling of confirmation/information SMS      result in an effective time resolution in the order of
              (secondary information)                         some 100 msec.
           This data shall be retrieved from the device at least once   This means that a fine-grained time recording as in-
           per day, and transmitted/uploaded to a target destina-  dicated by Figure 4-2 will not be possible and use case
           tion (typically by email).                         modelling will have to be restricted to main phases.
             For retrieval, several tools are available. For the pilot   From a practical point of view, this will be the overall
           project, the app “SMS Backup & Restore” has been se-  transaction time from invocation of the MoMo service
           lected. The app copies local SMS to a XML file. This file   to its completion (end to end duration), and the core
           can be stored locally and be sent to a remote destina-  transaction time, i.e. the time between triggering the
           tion via e-mail.                                   transfer after all input information has been provided,
             The following sub clause describes the model set-up   and its completion.
           of the app.                                          Data acquisition may deliberately be done fully man-
             After the data has been successfully uploaded, it can   ual, or points of observation to obtain trigger point
           be deleted on the device. The data file just uploaded   events may be limited. . In such a situation, some of the
           can be moved to a backup storage location. Until then,   generic KPI, as described in clause 5, are not applicable
           the data shall be kept on the device as a back-up copy.  due to the reasons described. The following set of prac-
                                                              tical KPI can be used:
           ■    NOTE: If the devices are restricted in functionality   In all cases, a valid sample requires that all trigger
             (e.g. to act as “Feature phones”, transfer via e-mail   points used in computation are valid, i.e. present. Indi-
             requires that these restrictions (e.g. “no mobile   cators of type ‘time’ are therefore computed from trans-
             data”) are removed for the transfer. It is important   actions where respective phases have been completed
             to re-establish the correct settings for DFS testing   successfully.
             afterwards, or prior to a new set of tests.        For the overall completion times, the E2E version us-
                                                              ing T1 was selected although it includes times for manu-
                                                              al activity. Reasoning is as follows: A KPI, as an indicator
           7  SPECIAL CONSIDERATIONS FOR MANUALLY             expressing the end-user perspective, should provide a
             OPERATED TESTING AND TIME-TAKING
                                                              realistic estimate of a service’s behavior. Manual activ-
                                                              ity is an integral part of service usage and therefore it
           The considerations described so far assume that    makes sense to include respective times into an indica-
           time-taking provides a precision of time measurement   tor. Assuming that a testing team can be compared to
           which is sufficiently higher than typical times for re-  an experienced user, times taken by such a team can be
           spective phases of the event flow.
                                                              viewed as a valid estimation of manual components of
                                                              service usage.


          TABLE 7-1: Timestamps (trigger points) used for the practical KPI

           SYMBOL     DESCRIPTION
           T1         Start of transaction (activation of the DFS function/application on the device)
           T2         All necessary input data has been entered and the actual money transfer is triggered.
           One of  T3  Reception of the primary success criterion (information about the successful completion of the transaction), or
                  T4  Reception of an information stating that the transaction has failed
                  T5  Time-out limit reached without a positive or negative reaction from the service
           T6         Reception of the summary SMS in the A-side mobile device
           T7         Reception of the summary SMS in the B-side mobile device
