6  ACQUISITION OF DATA ON DFS                      tion of the Ghana Pilot Campaign) where respective
             TRANSACTIONS                                     considerations have been used.
           6.1 Overview                                       6.2 Primary DFS data collection modes
           In order to compute DFS KPI, respective input data
           need to be collected.                              6.2.1 General remarks
             The method used should be robust and provide a   The procedures in the following are defined to provide
           high level of data quality. Robustness means that the   operational robustness. They include steps which are in-
           system should ensure security against loss of data. Data   tended to provide some redundancy and elements of
           quality  refers  to  aspects  such  as  reproducibility  and   data backup.
           plausibility tests to detect wrong data.             The term “uploading” is used in a functional way.
             Figure 6-1 is a graphical representation of measure-  Where smartphones are the platform (e.g. when taking
           ment data flow and handling. Please note that this is   a photo of a completed data log), it is assumed, unless
           a rather schematic and simplified view. Details given in   otherwise mentioned, that this means sending respec-
           the following sub clauses have precedence.         tive data by e-mail.
             In the present methodology a manual method will be   As far as PCs are the platform, it is assumed that FTP
           used to collect the primary information, i.e. timestamp   or http upload will be used. It is further assumed that for
           data for events needed to compute KPI will be entered   this upload, the ITU IFA server will be used.
           manually by a member of the measurement team.
             There is in addition, secondary information in the   6.2.2 Collection on paper, later transfer
           form of summary SMS sent by the system at the end   Paper printouts of respective tables are created. These
           of the transaction. These SMS will be read from the de-  printouts are called ‘data capture sheets’ (DCS) from
           vices in a bulk fashion, and also transmitted to the data   here on.
           processing system.                                   Each DCS shall carry some information to allow data
             For primary data collection on DFS transactions,   consistency and completeness checking:
           there are two possible approaches:                 -  Identification of the team.

           a) Collection  on  paper  and  subsequent  transfer  into   -  Date.
             electronic forms (e.g. Excel®).                  -  Location of test.
                                                              -  Running number of test in this specific location.
           b) Direct entry to electronic forms (e.g. Excel® tables).
                                                              When a new location is used, a new DCS is used.
           Both methods have their respective merits and will   During testing, the team member enters data manu-
           therefore be described subsequently. See also (Descrip-  ally into the DCS.


           FIGURE 6-1: Schematic overview of measurement data flow and handling


                      MoMo Service Test Data            MoMo Notifcation SMS       Background Measurements



                MoMo    • Record local condition in Location   Systems                   • Run active tests for
               Tests and     Log Forms               sends    • Automatically send   Active     primary carrier
                primary  • Record Transaction results to   Status SMS      SMS records to data   Tests     services (packet data,
                 data      Data Log Forms           on A and      destination               SMS, USSD)
               acquisition  • Record events in Event Log Forms    B side


                        • Transfer content of data forms
                Primary     to Excel tables          Convert   • Convert record          • Automatic data
                 data   • Mail Excel tables to data   SMS backup      content to SQL   Data     upload to DFS Data
                capture     destination              records     import code      Upload     Server
                        • Back-up procedures (photo/mail)



               Import to  • Import Excel tables to main   Import to  • Import notification   Import to  • Convert data and import
               database     database                             SMS to SMS database        into Background
                        • Data Validation            database  • Validate data   database     Measurement data base
                                                                                         • Data Validation

                                                 Process data to reports
