Industry-driven digital transformation




           • Upgrading Wireless TN: In addition, network operators  splitting) options range from tens to hundreds of µs. When
             also need to upgrade their wireless TN. In doing so,  more functions reside in DUs than RUs, C-RAN is more
             frequency spectrum, bandwidth, and the corresponding  beneficial, but heavy centralization creates more burden for
             wireless technologies affect link capacity, range (distance)  the front-haul network (FN), and there is a need to balance
             and other practical considerations.              functional splitting between RAN and FN. Upgrading FN is
             A 10 Gbps wireless link may be adequate for some  time consuming, and it is vital to decide early on C-RAN
             networks [15], but cannot be provided in sub 40 GHz  scenarios with priority given to dense urban areas [24].
             bands. In order to provide sufficient capacity, ETSI has  As stated above, it is beneficial to deploy C-RAN in 4G
             proposed to use mmWave bands, including V-band and  networks, which also facilitates deployment of centralized
             E-band which can provide up to 10 GHz bandwidth for  5G NR. However, CPRI interface in 4G networks is
             wireless links [20]. Studies are also underway to propose  TDM-based, which is inconsistent with packet-based 5G
             higher bands, including W-band and D-band.       fronthaul interfaces. To resolve this, the IEEE 1914 Working
             Another challenge is the provision of quality of service  Group has developed radio over Ethernet (RoE) standard for
             (QoS) in 5G for different services and a range of QoS  encapsulation of digitized radio over Ethernet frames. RoE
             requirements. However, wireless links are time-varying  includes a CPRI mapper that maps/de-maps CPRI frames
             and have diverse propagation characteristics that impact  into/from Ethernet frames. By utilizing RoE CPRI mapper,
             their QoS. Hence, different frequency bands are used  an Ethernet-based 4G C-RAN can be deployed and used for
             for different services, depending on QoS requirements.  5G C-RAN. In brief, centralization can begin from hotspots
             ETSI has introduced band and carrier aggregation (BCA)  in 4G, and then 5G NR base stations can be added when the
             technology to collect information from the media and map  capacity and latency requirements of fronthaul interfaces are
             each service to a proper band. BCA can extend the range  satisfactory.
             of wireless links by sacrificing availability [21].
                                                              5.3 Software-Defined Transport Networks
           • Expanding fiber-based TN: Gigabit passive optical  Software-defined networking brings many benefits such as
             networks (GPONs) are already deployed by many network  flexibility, scalability, and agility for TNs as specified in
             operators, but in some cases, cannot fulfill both capacity  the transport SDN (T-SDN), and can also be used for
             and latency requirements of 5G. NG-PON2 is a promising  deploying efficient TN slicing. Network slices are realized
             candidate for replacing GPONs, but may not be available  by coordinating the TN management system and E2E
             soon. As an alternative, standardization of 50 Gbps/100  management system.  A TN management system can be
             Gbps PON is underway. Ethernet interfaces should also  implemented via the SDN controller [17]. To evolve a legacy
             be upgraded to increase capacity. Although GbE may be  TN to T-SDN, TN devices and TN architecture should both
             sufficient for eNBs, they are inadequate for gNBs. Hence,  be upgraded. In what follows, we describe the upgrading
             GbE interfaces must be upgraded to 10 GE/25 GE for  of TN devices (i.e., forwarding/routing devices) and TN
             fronthaul interfaces. In brief, to increase TN capacity,  architecture.
             existing links should be upgraded first, to be followed by
             the deployment of new links.                     5.3.1  Upgrading Transport Network Devices
                                                              Migration Working Group of Open Networking Foundation
           5.2 C-RAN Deployment and Transport Networks        (ONF) has categorized three types of devices for 5G TN
           C-RAN is an efficient concept for optimal allocation of  deployment:
           resources in cellular networks, but TN is very challenging in  • Legacy devices: devices with integrated CP and DP;
           C-RANs. In 4G, the common public radio interface (CPRI)  • SDN-enabled devices: devices in which CP is decoupled
           is used, whose data rate linearly increases with bandwidth  from DP, and CP is external to the device; and
           and number of antennas. CPRI is not suitable for 5G with  • Hybrid devices: devices with both legacy DP and CP with
           more bandwidth and massive MIMO technology. Hence,   SDN capabilities. Many legacy devices are upgradable to
           enhanced CPRI (eCPRI) is introduced for TN in 5G, which  be SDN-enabled via software/hardware upgrades.
           exploits functional splitting to reduce latency and data rate  There are three approaches for migrating from legacy TNs to
           requirements compared to CPRI. Moreover, eCPRI utilizes  SDN-enabled TNs:
           cost-effective packet-based technologies such as Ethernet and  • Greenfield deployment [25]: upgrading existing TN
           IP, where F1 interface, also called mid-haul, is used to connect  devices to the SDN-enabled version.
           DUs to CUs, and NG interface connects CUs to 5G CN.  • Mixed deployment: co-existence of SDN-enabled devices
           The data rate and latency of interfaces are impacted by  with legacy devices, where the SDN controller and legacy
           3GPP functional splitting options. Option 2 (between radio  devices need to exchange routing information via legacy
           link control and packet data convergence protocol layers)  CP agents; and
           covers DU-CU functional splitting [17] (also called higher  • Hybrid deployment: co-existence of legacy, hybrid and
           layer splitting), with latency in the order of ms [22, 23],  SDN-enabled devices, where hybrid devices are upgraded
           while data rate is reduced to near the end-user data rate.  to become SDN-enabled, and legacy devices are gradually
           Latency for DU-RU functional splitting (called lower layer  replaced by SDN-enabled devices.
