BUILDING A DISTRIBUTED XR IMMERSIVE ENVIRONMENT FOR
                                               DATA VISUALIZATION




                                                 Fernando Beltrán; Jing Geng

                                             University of Auckland, New Zealand



                              ABSTRACT                        Having  experimented with a  handful of  free-to-access
                                                              environments, we decided to build our own application for
           We present a novel way to support business organizations’   the visualization of data sets on a range of diverse devices.
           decision-making in the context of analysis of network data   The two main types of data are tabular data sets and network
           sets. For such a purpose we built a mixed-reality, multi-user   data sets, and  on each we  seek to explore  how decision
           platform, which we named Aroaro and can be deployed on   makers able  to  visualize the  data that describes the
           different virtual reality and augmented reality devices.  In   connectivity characteristics  of  a network so  that  they  can
           Aroaro,  users can experience data visualization, either   provide answers to  questions posed as  decision-making
           individually or as  part  of  a team.  With  a set of lab tasks   problems. Our approach contemplates  decision  makers
           designed to lead lab subjects to  analyze the  network   facing two visualization  options:  data displayed  on a  2D
           information  while immersing into the rich virtual   interface –such as a computer screen, or data displayed on an
           environment, our approach belongs to the nascent area of   immersive 3D environment like the one presented here.
           immersive analytics. We assume a business unit has already
           procured some network data set  and  been tasked with   In terms of the components necessary to achieve the above-
           problems that need to reveal information about the   described approach  we set ourselves into a  demanding
           network’s connectivity properties. This paper is concerned   pathway as we had to conceive, build, and test the immersive
           with how a business unit achieves problem solving (decision-  software platform on  three different device  types: virtual
           making) when relying on immersive analytics. Our approach   reality for Head-Mounted Displays (HMDs), and augmented
           combines a high-quality virtual environment such as Aroaro,   reality for both HoloLens and Android-based smartphones.
           its data visualization engine and the analytics afforded by
           concepts of network centrality in a network. We report on   Next, we  moved beyond  tabular data sets to  explore  the
           preliminary results of  having lab subjects experience two   higher complexity  of  network structures.  Users of Aroaro
           visualization environments: a 3D visualization system on a   data visualization tools  have a wide  range of  options for
           2D-flat screen and our mixed-reality, multi-user platform for   visualizing tabular data sets, but as rich as they may become,
           network data visualization.                        tabular data sets do not necessarily convey information about
                                                              existing relationships or  link between  the  entities, also
              Keywords – Augmented reality, data visualization,   known as nodes.  A  network data set, on the  other hand,
             immersive analytics, multi-user, mixed-reality platform,   necessitates two data files: the node set and the link set. It is
                      network data set, virtual reality.      the latter that contains the  connectivity information of a
                                                              network. This paper is only concerned with network data set
                          1.  INTRODUCTION                    visualization.

           We present a novel way to support business organizations   We envision a business unit that has already procured some
           decision-making in the context of business analysis that   network data set of its interest and  has  been tasked with
           requires managers  to deal  with network  connectivity   problems that make it select one  or  more nodes. Let us
           information stored in the format of a network data set. Our   provide more context to the  latter claim. Assuming the
           approach  relies on a mixed-reality, multi-user platform   network data set describes a network of individuals, such as
           where  one  or  more individuals can visualize the data set   the case of an Internet-based social network, the decision-
           while immersing themselves in a different kind of experience.  making team needs to find, according to some predefined
           We have developed the software that allows the virtual and   criteria, which subjects are  the most important. Their
           augmented  reality versions of the  platform to be used  by   objective, perhaps, is to reach out to those individuals who,
           interested parties. We call our immersive platform Aroaro, a   because of their importance, can help the business propagate
           Maori language word for “presence”.                a message on its behalf.
