Industry-driven digital transformation




           3.2.2   Boosting  power based  on overlapping  resource   parameters  for  different  transmission  time-frequency
           proportion                                         resources further improves the accuracy of power control.

           Multiple  overlapping  resource  proportion  thresholds  are   3.3   Design  for  dynamic  selection  of  DPCI  and
           defined in advance, among which the overlapping resource   ROPC
           proportion  is  defined  as  the  proportion  of  overlapping
           resources  to  URLLC  resources.  The  threshold  includes:
           10%,  40%,  80%.  Table  2  defines  a  mapping  relationship
           between the actual overlapping resource proportion x and a
           power  promotion  value.  For  example,  the  overlapping
           resource proportion is 40%, if URLLC resource is 10 RB and
           the  overlapping  resource  is  4  RB.  In  such  cases,  the             cell center
           transmission power of URLLC will be increased by 3dB.
                                                                                     cell edge

                                                                    URLLC UE(without Power Constrained )
                Time-frequency   Time-frequency   Time-frequency
               resource indication   resource indication   resource indication   URLLC UE(Power Constrained)
                  field 1    field 2            field n             eMBB UE(support DPCI)
                                                                    eMBB UE(do not support DPCI)
                         Time-frequency resource indication field
                                                                  Figure 7 – An example for the dynamic selection
              Figure 6 – Time-frequency resource indication field
                                                              In this subsection, we combine DPCI with ROPC to obtain
           The execution procedure of ROPC is summarized as follows:   better  performance.  Two  methods  for  the  multiplexing
                                                              application  can  be  considered  in  the  service  multiplexing
           a.   The  gNB  determines  which  group  of  URLLC  time-  system model, and the most suitable method is selected for
               frequency resources overlaps with the eMBB.    execution  in  one  TTI.  Figure  7  shows  an  example  for

           b.   The  gNB  computes  the  overlap  proportion  between   dynamic  selection  multiplexing  methods  based  on  the
               each  group  of  URLLC  time-frequency  resources  and   location and function configuration of the UE. There are both
               eMBB time-frequency resources.                 a URLLC UE and eMBB UE in a cell. For the URLLC UE,
                                                              one  kind  of  UE  can  perform  ROPC  without  the  power
           c.   The  gNB  sends  the  control  information  carrying  the   constrained, and the other kind cannot perform PC with the
               index  of  power  control  parameters  corresponding  to   power  constrained.  For  an  eMBB  UE,  one  kind  of  UE
               each resource group according to the calculation result   supports DPCI, and the other kind does not support DPCI. In
               of the 2  step.                                practical application, there are three options for multiplexing
                     nd
                                                              scheduling:  ROPC,  DPCI  and  no  scheme,  and  Figure  8
           d.   The  URLLC  UE  receives  and  decodes  the  control   shows  the  selection  procedure  of  the  multiplexing
               information of ROPC.                           mechanism.

           e.   The  URLLC  UE  determines  the  power  value  to  be
               enhanced  for  each  group  time-frequency  resource                START
               according to the index in the time-frequency resource
               indication field.
                                                                             N                Y
                                                                                   DPCI first?
              Table 2 – Power boosting value according to actual
                      overlapping resource proportion
                                                                 URLLC UE power   N  Performing   eMBB UE support
                             Actual overlapping   Power            constrained?     ROPC           DPCI?
                Index                                                                         Y
                            resource proportion x   boosting(dB)
                                                                    Y               END             N
                  0              x ≤ 10%            0
                  1           10% < x ≤ 40%         3            eMBB UE support   Y  Performing   N  URLLC UE power
                  2           40% < x ≤ 80%         6               DPCI?           DPCI          constrained?
                  3              x > 80%            9
                                                                    N               END             Y
           The introduction of overlapping resource proportion enables
           a URLLC UE to adjust the transmission power to be optimal,              No scheme
           while limiting the interference for the eMBB transmission.
           What’s  more,  interpreting  different  power  control                   END
                                                                    Figure 8 – The dynamic selection procedure





                                                           – 49 –
