II.3  MAPPING OF ACQUIRED DATA TO FORMAL            scription, or to the mobile device. For the tests, the
              TRIGGER POINTS                                  USSD code *135# has been chosen which queries the
                                                              own telephone number. In addition, using a code, which
          By comparison to the full trigger point list shown in in   relates directly to DFS, should not be used, as this may
          Table 4-2, the timestamps used in the Ghana pilot cam-  bring the DFS system into undesired states. Suitable
          paign, as shown in Table II 1 are a subset (see the full dis-  USSD codes would serve as suitable proxies for the
          cussion of consequences of manual execution of tests   functioning of the USSD subsystem in the network un-
          in clause 7). Consequently, a mapping of timer flags to   der test, without having undesired side effects.
          formal trigger points needs to be done and is shown in   For the choice of web sites, small sites were selected,
          Table II-1.                                         i.e. the Google search engine start page, and the ETSI
             Please note that there are no format trigger points   Kepler for Smartphones page  hosted on a reference
                                                                                         6
          for T4 and T5, as they are not linked to events from the   server.
          activity flow in a DFS implementation. In case of T4, it   Even though the DFS implementation in Ghana uses
          will be set from a failure indication given by the DFS im-  USSD and SMS as its principal carrier services, packet
          plementation which cannot be provoked directly from A   data related test cases have been added to collect some
          or B side, but needs to be interpreted as part of human   potentially useful additional information.
          or automated monitoring of the test. In case of T5, it is   After some validation tests, it has been determined
          set by a time-out condition determined by some exter-  that using a data server in Germany (hosted at Focus
          nal time-keeping process.
                                                              Infocom) provides the best operational value also with
                                                              respect to maintenance. During the pre-pilot phase, a
          II.4  BACKGROUND TESTING OF THE TRANS-              second server (at Strato, a large German web hosting
               PORT NETWORK                                   system) has been tested and verified to work. This was
                                                              done to make sure a fallback solution is available in case
          For  SMS testing,  sending  SMS to  the  same  device  is   of server problems during the campaign.
          used to simplify data capture.
             For USSD testing, a code (or multiple codes) should
          not make permanent changes to the state of the sub-

          Table II-1: Reference table: Ghana campaign timestamps to formal trigger points
             TIMESTAMP    FORMAL TRIGGER POINT   REMARKS
                 T1              AA_100          Start of test case execution
                T2               AA_200          Start of core transaction
                T3               AE_300          Successful completion of transaction
                T4                               Used as failure indicator
                T5                               Used as timeout indicator
                T6               AE_310          Reception of information SMS on A side
                T7               BE_320          Reception of information SMS on B side
