6.5 Relationship between trusted inter-cloud and the cloud computing reference architecture

The cloud computing reference architecture [ITU-T Y.3502] provides an architectural framework which
defines cloud computing roles, sub-roles, cloud computing activities and cross-cutting aspects. It also
describes the functional layers and functional components of a cloud computing system. According to this
framework, the trusted inter-cloud relationships can be expressed by cross-cutting aspects like security,
governance and resiliency that span over cloud computing multi-layer functionality. The conceptual view of
cloud computing management is based on cloud computing management layers and the service
management interface (SMI) approach [ITU-T Y.3520] and [ITU-T Y.3522].
Trust management in inter-cloud environments can be realized based on the common model for end-to-end
cloud computing management [ITU-T Y.3521]. In particular, the operations support system (OSS) functional
components encompass the set of management capabilities that are required in order to manage and control
trust in an inter-cloud environment. The role of business support system (BSS) functional components
remains to encompass the set of business-related management capabilities dealing with customers and
supporting processes in a trusted manner (see clause 9.2.5.4 of [ITU-T Y.3502]). Therefore, in a trusted inter-
cloud environment, the cloud computing management functionalities [ITU-T Y.3521] can be used to reach
objectives of trust satisfying governance, security and resiliency aspects of inter-cloud.

7 General requirements for trusted inter-cloud
This clause identifies general requirements applicable to trusted inter-cloud.

7.1 Data separation
It is required that the CSP provides data separation between workloads to ensure security and confidentiality.

7.2 Data annotation

It is recommended that the CSP supports annotation (tagging) of trusted inter-cloud data (workloads) to
enable compliance with regulatory obligations.

7.3 Confidentiality of data

It is required that the CSP respects the confidentiality of the CSC's or CSP's data used in trusted inter-cloud
system.

7.4 Operational statistics
It is recommended that the CSP supports operational statistics for trusted inter-cloud services according to
appropriate methods of measurement.

7.5 Interoperability and dependability

It is recommended that the CSP supports interoperability and dependability of trusted inter-cloud services.

7.6 Master service agreement
It is recommended that the CSP respects master service agreements to reach objectives of trust satisfying
governance, security and resiliency aspects of inter-cloud.

8 Requirements for governance of trusted inter-cloud
This clause provides requirements for governance of trusted inter-cloud derived from the use cases described
in Appendix I.

8.1 Geographical policies
It is required that the CSP respects all applicable geographical policies in order to realise requests from the
CSC or other CSP.
