ITU Journal: ICT Discoveries, Vol. 3(1), June 2020



          used for the exhibition, Kirari! for Arena can also be   that consists of four displays and four half-mirrors,
          constructed with it to reconstruct the direction of   compared  with  existing  presentation  devices
          sound.                                               containing  many  projectors  and  special  optical
                                                               devices. Kirari! for Arena is realized by combining
          Table 3 – List of ILE requirements and conformance status of
                           Kirari! for Arena                   functions  for  real-time  image  extraction,  object
                                                               tracking, synchronous media transport, and depth
                                                Kirari!
          No.       Requirements       Manda   for Arena       expression.  Item-wise  evaluation  shows  that  it


                                        -tory
                                                               conforms to ITU-T H.430. Further standardization
          1   Life-size display                                work  on  ILE  and  collaboration  with  related
          2   Direction of sound       ✔      ✔                standardization bodies are required.
          3   Atmosphere reconstruction       ✔ (5.1)          REFERENCES
          4   Spatial reconstruction   ✔      ✔ (4.6)          [1]   J. Nagao, H. Miyashita, T. Sano, K. Hasegawa, T.
          5   Synchronous representation   ✔   ✔ (4.5)               Isaka  (2019),  “Kirari!  for  Arena  :  Real-Time
          6   Augmented information                                  Remote Reproduction of 4-Directional Views
          7   Real-time object extraction   ✔   ✔ (4.3)              with  Depth  Perception,”  Journal  of  the
          8   Spatial object information      ✔ (4.4)                Imaging Society of Japan, Vol. 58, Issue 3.
          9   Synchronous transmission   ✔    ✔ (4.5)          [2]   Recommendation  ITU-T  H.430.1  (2018),
          10  Data storage                                           Requirements for immersive live experience
          11  Reconstruction processing   ✔   ✔ (4.6)                (ILE) services.
          12  Auditory lateralization
          13  Video stitching                                  [3]   Recommendation  ITU-T  H.430.2  (2018),
                                                                     Architectural  framework  for  immersive  live
          5.2  Discussion on further study                           experience (ILE) services.

          Although Kirari! for Arena conforms to ITU-T H.430,   [4]   Recommendation  ITU-T  H.430.3  (2018),
          it has several aspects to be improved because it was       Service scenario of immersive live experience
          an experimental development. First, it was not life-       (ILE).
          size.  Second,  auditory  lateralization  should  be
          integrated  for  a  stronger  sense  of  reality.  Past   [5]   Recommendation  ITU-T  H.430.4  (2019),
          Kirari!  events  proved  their  feasibility  and           Service  configuration,  media  transport
          effectiveness  [20].  Augmented  information  may          protocols and signalling information of MMT
          also enhance the audience experience. These issues         for Immersive Live Experience (ILE) systems.
          would require further research and development to    [6]   Dolby 3D. 2018. Retrieved from
          determine  the  appropriate  methods  for  real-time       http://www.dolby.com/us/en/technologies
          transport  and  processing.  Data  storage  and  video     /dolby-3d.html.
          stitching  may  also  be  integrated  wherever  such
          functions are necessary.                             [7]   RealD. 2019. Retrieved from
                                                                     http://reald.com/.
          On the standards side, it may be worth considering                       TM
          standardizing  issues  such  as  reference  models  of   [8]   XPANDVISION  3D Cinema. 2019. Retrieved
          presentation environments. Further collaborations          from  http://xpandvision.com/cinema/.
          with  immersive  service-related  standardization    [9]   4DX. 2019. Retrieved from
          bodies,  such  as  ISO/IEC  JTC1,  especially  MPEG,       http://www.cj4dx.com/.
          3GPP, and DVB, also need to be continued.
                                                               [10]  Media  Mation  MX4D.  2019.  Retrieved  from
          6.   CONCLUSION                                            http://mx-4d.com/.

          ILE  services  can  bring  people  unprecedented     [11]  Y.  Mizushina,  W.  Fujiwara,  T.  Sudou,  C.  L.
          experiences.  This  article  introduced  Kirari!  for      Fernando,  K.  Minamizawa,  S.  Tachi  (2015),
          Arena  as  one  implementation  of  ILE,  which            “Interactive  instant  replay:  sharing  sports
          reconstructs  the  atmosphere  of  sports  or              experience  using  360-degrees  spherical
          entertainment events using a four-sided display and        images  and  haptic  sensation  based  on  the
          depth expression to provide audiences anywhere in          coupled body motion,” AH ’15.
          the  world  with  a  highly  realistic  sensation.  The
          display device has a relatively simple configuration




                                                © International Telecommunication Union, 2020                 39
