not shown where they should be. They might look the system gave realistic sensations to a fair number
either higher (like the objects are floating) or lower of people. Similarly, the positive responses (16)
(sunk into the floor) than the ideal positions. were four times as many as the negative responses
Therefore, the positions of the objects (object (4). This shows the efficacy of the system. There are
images produced by the real-time object extraction) 2 responses categorized as “Not stereoscopic
are transformed by viewpoint transform for Kirari! enough.” It is natural to have a certain number of
for Arena [34]. such responses because the display is 2D in
principle. Providing a stronger sense of depth
would be future work.
Table 1 – Audience responses
Stance Category Quantity Subtotal Total
Useful 10
Fig. 8 – Object position perceived by a viewpoint different Positive Realistic 5 16
from a camera Low latency 1 20
The parameters of the transform are acquired in Not stereoscopic 2
advance from the physical positions of the cameras Negative enough 2 4
Has latency
and their calibration with the performing stage.
Table 2 shows some examples of the responses
The position of the object reconstructed with the 3D
position information was more stable than previous categorized as “Useful” and “Realistic.” They are
studies [35][36] using background subtraction and shown because these categories have a wide variety
cropped input image. of responses. The “Realistic” responses show that
the performer looked as if he was really in the
5. EVALUATION AND DISCUSSION device. Such realistic sensations were stimulated
because the image from the source site was
Kirari! for Arena was demonstrated at an exhibition effectively fused into the surroundings in the
in December 2018. There were more than 200 display device at the remote site by combining real-
exhibits and the total guest count was more than time image extraction and depth expression. These
14,000 people.
responses could confirm that the atmosphere was
Commercially available PCs (specifications varied reconstructed by the system.
up to two 22-core 2.2-GHz CPUs, 32 GB RAM, GPU) Table 2 – Examples of responses
were used to construct the Kirari! for Arena system.
The system could process 4K (3840 x 2160 pixels) Category Responses
images with a frame rate of 59.94 fps.
Evaluating experience is quite a problematic task, Useful It would be great if we have this in our home.
but audiences of such experiences provide Useful It would be good for streaming of live
responses that can be used to estimate an objective concert.
evaluation of the system. A total of 98 relevant Useful I want to watch Sumo on this.
responses interviewed by the exhibitors were Realistic Looks as if he’s really there.
collected through the exhibition, and 20 of them Realistic It’s too real it’s scary.
were useful for evaluating the system. First, the 5.1 Conformance to ITU-T H.430 series (ILE)
responses were sorted into positive and negative of standards
stances. Then, they were further categorized into
smaller categories for each stance. Table 1 shows Kirari! for Arena conforms to the ITU-T standards
the categorization results. by fulfilling all of the mandatory requirements.
As these are free comment responses, the 5 Table 3 summarizes the requirements specified in
categorized as “Realistic” does not necessarily mean ITU-T H.430.1 and the conformance status of Kirari!
the remaining 15 did not evaluate the system as for Arena. The numbers in the column “Kirari! for
“Realistic.” On the contrary, the fact that at least 5 Arena” indicates the subclauses in this article
people out of 20 actively expressed their describing the functions and evaluation results that
impression that the display was “Realistic” means fulfill the requirements. Although wave field
synthesis technology with a speaker array was not
