5 Intercloud and interoperability

Table II.12 – Test case: physical machine life cycle management

Physical machine life cycle management test description
7 Stimulus The CSC wakes up the physical machine which is in hibernate
state.
8 Check The state of the physical machine is power on.

Test verdict It is deemed as successfully terminated if all the checks are successful, otherwise it is
deemed as failed.

II.1.13 Test case: VM configuration inquiring

Table II.13 shows the test case for VM configuration inquiring.

Table II.13 – Test case: VM configuration inquiring

VM configuration inquiring test description
Test purpose To verify that the CSC inquires VM configuration with CPU number, memory allocated,
NIC number, IP address allocated.
Reference [ITU-T Y.3513] clause 7.1.2
Test sequence Step Type Description Result
1 Stimulus The CSC queries the CPU number of the VM.
2 Check The CSC receives the information of a particular VM's CPU
number that is consistent with the number of the CPU
allocated for the VM.
3 Stimulus The CSC queries memory size of the VM from the CSP.
4 Check The CSC receives the information of a particular VM's
memory size that is consistent with the size of memory
allocated for the VM.
5 Stimulus The CSC queries the NIC number of the VM from the CSP.
6 Check The CSC receives the information of a particular VM's NIC
number that is consistent with the number of the NIC
allocated for the VM.
7 Stimulus The CSC queries the IP address of the VM from the CSP.
8 Check The CSC receives the information of a particular VM's IP
address that is consistent with the IP address allocated for
the VM.
Test verdict It is deemed as successfully terminated if all the checks are successful, otherwise it is
deemed as failed.

II.1.14 Test case: physical machine configuration inquiring
Table II.14 shows the test case for physical machine status inquiring.

Table II.14 – Test case: physical machine status inquiring

Physical machine configuration inquiring test description
Test purpose To verify that the CSC inquires physical machine configuration with the number of CPU
cores, memory size, disk size and NIC number.
Reference [ITU-T Y.3513] clause 7.1.1
