Big data - Concept and application for telecommunications                       5


            6.12    Big-data-driven content delivery network deployment

            The  content  delivery  network  (CDN)  has  been  considered  by  MNOs  as  an  efficient  delivery  method  for
            popular  content, such  as blockbuster movies. The main  purpose  of  having  their own  CDNs  is  to  reduce
            operational costs while providing good support to their core businesses. The deployment of CDN based on
            big data technology is the most effective.

            6.12.1  Big-data-driven cache server deployment in content delivery network
            It is important to locate distributed cache servers in the CDN as close to the end user as possible in order to
            shorten response time and also reduce delivery costs, e.g., a distributed cache server working together with
            a central cache server in a hierarchical CDN. However, the cache access rate on the distributed cache server
            might be lower than that of the central cache server. Sometimes the distributed cache server even needs
            user data traffic to traverse the associated central cache server through the link in the event of improper
            placement. Therefore, it is vital to choose the optimum location for the cache servers in the hierarchical CDN.

            Beside the cost of storage and streaming equipment, the features and load of traffic in a given area are among
            the important factors that determine the optimal placement of a cache server. After collecting data relating
            to all relevant factors in the coverage area over a long period of time, big-data analysis can be used as a
            feasible method in data analytics to help the MNOs deploy cache servers in the network.
            The  analytics  capabilities  are  built  into  the  hierarchical  CDN  by  utilizing  a  collective  intelligence  data
            architecture. Each cache server has a monitor agent to collect log information. This monitor agent sends log
            status information to the data analytics function block, which then determines when and what content to
            outsource, as well as placement of the replicas.

            Therefore,  the  data  analytics  function  needs  to  analyse  the  data  related  to  both  content  and  users  to
            accurately determine or predict content popularity.
            6.12.2  Big-data-driven content scheduling in content delivery network

            Content of high popularity is more likely to be placed on cache servers in RAN to improve the cache access
            ratio popularity, while content of low popularity can be placed on cache servers in an edge provider. The
            content popularity analysis depends on not only the content itself, but also users. Moreover, user mobility
            may  cause  the  content  in  the  cache  to  change  frequently,  resulting  in  inefficiency  in  content  caching.
            Therefore, the data analytics function needs to analyse the data related to both content and users in order
            to accurately determine or predict content popularity.

            Overall, content popularity analysis and content scheduling require collection of the following data:
            1)      user  data:  the  location  and  access  pattern  of  users,  which  can  be  collected  from  the  interface
                    between SGSN and GGSN;

            2)      content data: crawling from the Google or public website.
            6.12.3  Content transmission control to end user of content delivery network in big-data-driven
                    networking
            Due to physical space storage, cache nodes in a mobile network are limited, while cache nodes in a fixed
            network specially deployed in the data centre are almost infinite. So, cache nodes in a mobile network can
            only store limited content. There is a requirement to transmit data among cache nodes. Figure 6-11 depicts
            content transmission control to the CDN end user in bDDN. The process is as follows:

            1)      a mobile user watches a video from the cache node deployed in the fixed network;
            2)      other mobile users request the same content;
            3)      the big-data plane, sensing the request, transfers data from cache node deployed in fixed network
                    to the cache node deployed in the mobile network that is nearest to these mobile users;
            4)      mobile users get the content from the cache node deployed in the mobile network;






                                                                           Network and infrastructure    239
