P. 131

Connecting physical and virtual worlds




           2.1   Pose estimation                              2.2.1    Vector auto-regression

           The pose estimation technique  forecasts and tracks the   A multivariate time series has numerous time-dependent
           location of an individual person or object. This is carried out   variable [9]. Each variable relies not only on its past values
           by looking at a combination of the pose and therefore the   but also has  some dependency  on other  variables.  This
           orientation of a given person. It is typically performed by   dependency is employed for forecasting future values.
           identifying, locating, and tracking a number of key points on
           the person’s skeleton  estimated data.  Considering  each   Each variable in a VAR model is a linear function of the past
           skeleton with N joints, including head, neck, arms and legs,   values of itself and old values of all the other variables. The
           every joint position is interpreted in the image coordinate   two-time dependent variables are image array data (y 1) and
           with coordinate values of x and y, so there is a total of 2N   key points  (y 2). These variables influence each other.  To
           points for each skeleton. The Part Affinity Fields (PAFS) are   compute y 1(t), the past values of y 1 and y 2 are used. Similarly,
           used to associate the joints of an individual [7]. These values   for calculating y 2(t), past values of both y 1 and y 2 are used.
           are concatenated and used as the skeleton information of the
           human subject for each frame processed.                                 ∗        1            ∗        1




                                                                       1                                                                        (3)

           2.1.1   Centroid method
                                                                                    ∗        1            ∗        1




           A unique Identification (ID) is assigned to each centroid after            1                                                                        (4)

           computation, then new centroids are computed in the next
           frame. The Euclidean distance between the centroids of the   where a 1 and a 2 are the constant terms, w i , w i , w i , and
                                                                                                         21
                                                                                                     12
                                                                                                11
           current and  former frames are correlated based  on the   w i  for i = 1, 2, are the coefficients, and e 1(.) and e 2(.) are the
                                                                22
           minimum distance [8]. If the correlation is found, the new   error terms.
           centroid is updated with the ID of the old centroid of the
           same color. If the correlation isn’t found then the  new   2.3   Bi-LSTM
           centroid is given a unique ID and a different color. If the
           person goes out of the frame for a set amount of frames, the   In Bidirectional Long Short-Term Memory (Bi-LSTM), the
           ID is removed.                                     output at any time is not only dependent on the past frames
                                                              within the sequence, but also on the future frames. The two
           In a  video frame  with  multiple objects, tracking each   LSTM are stacked on top of every other, where one LSTM
           individual object requires a technique to distinguish between   goes within the forward  direction and  another in the
           different key points. The centroid method is used  to   backward direction. The combined output is then calculated
           differentiate the key points of each individual. The centroids   based on the hidden layers of  both LSTMs  [10]. The
           are computed using the formula (1).                architecture of a basic unit of LSTM used in Bi-LSTM is
                                                              shown in Figure 2.
                ,                      ⋯       /   ,





           ⋯      /                                      (1)

                                                          th
           where x i and y i represents the x and y coordinates of the i     x            +
           key point on joints of an individual.
                                                                                                  tanh
           2.2   Activity forecasting
           Activity forecasting methods have been developed to cope                       x          x
           with the unavailable data for the analysis  due to  network
           issues in the  communication channel of  the surveillance
           system.  During the streaming of the video, if the  videos                  tanh
           pause for a few seconds, then the future pose and motion of
           the individual is predicted. It is trained using Vector Auto-
           Regression (VAR) with the videos from human activity data
           sets. The forecast takes the form as given in Equation (2)
                                    ⋯                      (2)







                                                                     x t
           where b 0  is the intercept, and b 1, b 2,..., b n  are coefficients
           which represents the contribution of independent variables   Figure 2 – A basic unit of LSTM used in Bi-LSTM
           X 1, X 2 ,..., X n.
                                                              The general architecture of  Bi-LSTM utilized  in  the
                                                              proposed method has the external structure of the training

                                                           – 69 –
