1                                    Framework and requirements for cloud computing


                                                      Appendix II


                                  Use cases from cloud service providers' views
                            (This appendix does not form an integral part of this Recommendation.)


            This appendix describes nine inter-cloud related use cases from the perspective of the cloud service provider.

            Introduction to participants

            For the purpose of this analysis, the following participants are considered. Each of the boxes in Figure II.1
            represents a cloud service provider (CSP).



                                      Enterprise   I 4C                I 5C
                                       private              CSP D              CSP C
                                       cloud



                                                           I 2C                   I 2C
                                                                   I 2C    I 2C
                                                       I 3C
                                                                       I 1C
                                                            CSP A              CSP B
                                        CSC
                                                                              Y.3511(14)_FII.1

                                    Figure II.1 – Inter-cloud participants and relationships

                       Participant                                     Description

             User                           The human or machine end-user of the overall cloud computing service.
             CSP                            Cloud service provider: Party (e.g., information technology (IT) or telecom
                                            organization) which makes cloud services available. This may include any of
                                            the cloud services (SaaS, CaaS, PaaS, IaaS, and NaaS).

             Enterprise private cloud       IT resources within an enterprise that are constructed using cloud computing
                                            technologies, but which are owned and operated by the enterprise for their
                                            own internal use.
             Not included for inter-cloud   –  Hosting services using non-cloud technologies.
                                            –  Connectivity services not employing cloud technologies.
             The above categorization of participants is for the purpose of use case analysis only and does not imply
             specific business or regulatory situations. Not all participants identified will be present in all situations.
             Some organizations may fulfil multiple participant roles.

             Relationship                   Description
             ICn                            Inter-cloud relationship (focus of study)
            The relationships labelled on the diagram are used to clarify the use cases and do not necessarily indicate
            information flows or interfaces that require standardization by ITU. The relationships shown as dashed lines
            (- - - -) in Figure II.1 are included for completeness and are outside the scope of inter-cloud.












            306
