Framework and requirements for cloud computing                              1


            I.6     Market transactions in inter-cloud intermediary pattern

            Table I.6 shows inter-cloud use case for market transactions in inter-cloud intermediary pattern.


                    Table I.6 – Inter-cloud use case: Market transactions in inter-cloud intermediary pattern

                                                         Use case
             Use case title              Inter-cloud use case: Market transactions in inter-cloud intermediary pattern
             Relevant roles              CSP and CSC
             Use case description        –  The primary CSP in an inter-cloud intermediary pattern (CSP-Intermediary)
                                            mediates between CSPs meeting the CSC's quality requirements and provides
                                            the list of selected CSPs to the CSC.
                                         –  The CSP-Intermediary coordinates multiple services offered by other CSPs.
             Information flow            –  The SLAs of the CSPs are submitted to the CSP-Intermediary in advance.
                                         –  A CSC requests the CSP-Intermediary to select CSPs that provide a service
                                            which satisfies the CSC's quality requirements.
                                         –  The CSP-Intermediary compares the CSC quality requirements with the SLAs
                                            of other CSPs. Then the CSP-Intermediary discovers and reserves the CSP
                                            resources that meet the CSC's quality requirements.
                                         –  The CSP-Intermediary returns the CSP candidate list to the CSC.
                                         –  The CSC selects a CSP or CSPs on the list.
                                         –  The CSP-Intermediary sends a cloud service adaptation request to the
                                            selected CSP to invoke the service and adapt it to concrete cloud services and
                                            resources.
                                         –  The CSP returns an adaptation response to the CSP-Intermediary.

             High-level figure describing the   1. The CSC requests the service   CSP
             use case                        from CSP-Intermediary. The request
                                             includes CSC's quality requirements.
                                                                    CSP
                                             CSC                 (Intermediary)
                                                                                       CSP
                                                     3. C-CSP intermediary
                                                     informs the CSC of
                                                     the candidate CSPs.     2. CSP-Intermediary compares the quality requirements
                                                                             (including priorities) of CSC with the SLAs of
                                                                      CSP    multiple CSPs. The CSPs reserve the resources.
                                                                                                 Y.3511(14)_FI.Tab6
                                                4. The CSC chooses
                                                some of the CSPs
                                                and accesses them.

             Derived requirements for    The system is required to support:
             cloud capability            –  Policy negotiation including SLA management among the multiple CSPs
                                            including CSP-Intermediary in a pre-established group;
                                         –  Discovery, reservation, use and release of cloud resources in a dynamic
                                            manner (i.e., not relying on the pre-configuration) on other CSPs within the
                                            federation;
                                         –  Creation of the network connections in a dynamic manner (i.e., not relying on
                                            the pre-configuration) from the CSC to the selected CSP that provides the
                                            resources;
                                         –  Flexible reallocation of applications, to meet requirements at different stages
                                            in its lifecycle, across multiple CSPs.















                                                                                                         305
