1                                    Framework and requirements for cloud computing


                                                              Inter-cloud federation


                                                                    CSP B
                                                                    s
                                      CSC 1  Service X
                                                           p
                                                       CSP A  p                s  CSP C
                                            Service Y     p
                                   CSC 2

                                                             s
                                            Service Z
                                   CSC 3                    CSP E          CSP D

                                   p   Primary CSP                             Y.3511(14)_F8-3
                                   s   Secondary CSP


                                    Figure 8-3 – CSP A offering services as the primary CSP
                                              with the help of secondary CSPs
                                                              Inter-cloud federation



                                                                    CSP B

                                      CSC 1  Service X

                                                        CSP A                   CSP C
                                            Service Y     s
                                   CSC 2


                                                              p
                                            Service Z
                                   CSC 3                   CSP E  p       s CSP D


                                   p   Primary CSP                             Y.3511(14)_F8-4
                                   s   Secondary CSP


                                    Figure 8-4 – CSP E offering services as the primary CSP
                                              with the help of secondary CSPs


            A given CSP can act as a primary CSP and secondary CSP, i.e., using the services of secondary CSPs (e.g., CSP
            A in Figure 8-3) and providing services to a primary CSP (e.g., CSP A in Figure 8-4).
            8.2.3   Network connectivity

            In order to deliver cloud services based on the use of inter-cloud computing, network connectivity is required
            among the involved CSCs, primary CSPs and secondary CSPs. Specifically, this includes:
            –       Connectivity between peer CSPs. By means of this connectivity, a primary CSP can interwork with
                    the secondary CSPs to request a service (e.g., backup of data or transfer of virtual machines between
                    connected  CSPs).  In  some  cases,  this  connectivity  is  provided  on-demand;  the  connectivity  is
                    established instantaneously as the need arises and removed after the need disappears;








            288
