1                                    Framework and requirements for cloud computing


             Role/Sub-role    DSF service customer (CSC:CSU)
                              DSF service provider (CSP:SFP, CSP:DMP)
                              DSF local storage provider (CSP:CSM)
             Figure (optional)
























             Pre-conditions
             (optional)
             Post-conditions
             (optional)
             Derived          –  Clause 8.4 requirement (1)
             requirements     –  Clause 8.4 requirement (4)


            I.5     Policy-driven provisioning and management of data

             Title            Policy-driven provisioning and management of data
             Description      DSF service provider provides a unified interface to use DSF local storage and options to set
                              data manipulation policies. DSF service provider configures the data manipulation policies
                              because the data manipulation policies are independent from multiple data storages in DSF
                              local storage. DSF service customer uses a single virtual volume (e.g., upload, download, copy,
                              modify, delete and so on) and sets data manipulation policies (e.g., non-sharing, read-only,
                              overwrite, replicate and so on) to saved files. DSF service provider applies data manipulation
                              policies onto data operation metadata. DSF service provider manipulates data by
                              corresponding functions and APIs with data manipulate policies.
                              DSF service customer #1 sets data manipulation policy. DSF service provider modifies data
                              operation metadata of target data. Another DSF service customer (e.g., DSF service customer
                              #2) searches and gets data by using catalogue. In this procedure, the data operation metadata
                              is used in order to lookup data from DSF local storage.
             Role/Sub-role    DSF service customer (CSC:CSU)
                              DSF service provider (CSP:SFP)
                              DSF locals storage provider (CSP:CSM)
