Handigol, N., B. Heller, V. Jeyakumar, B. Lantz, and N. McKeown. “Reproducible network experiments using
container-based emulation.” 8th Conference on Emerging networking experiments and
technologies. ACM, 2012. 253-264.
ITU. “FG IMT-2020: Report on Standards Gap Analysis.” TD 208 (PLEN/13), SG-13, 2015.

Jangam, Anil, Ravi Ravindran, and et al. “Realtime Multi-Party Video Conferencing Service over Information-
Centric Network.” Workshop on Multimedia Straming in ICN (MuSIC). 2015.

KDDI Labs. “Press Release.” 2015. http://www.kddilabs.jp/press/2015/0525.html .
Liu, L., L. Xie, M. Bahrami, and et al. “Demonstration of a functional chaining system enabled by named-
data networking.” ACM ICN. Kyoto, Japan, 2016.
Mosko, Marc. Header Compression for TLV-based Packets. 5 Nov 2015.
https://www.ietf.org/proceedings/94/slides/slides-94-icnrg-0.pdf (accessed Dec 20, 2016).
Named Data Networking. NDN: Named Data Networking. 2016. http://named-data.net (accessed 2016).

NGMN. “NMGM 5G White Paper.” 17 Feb 2015.
https://www.ngmn.org/uploads/media/NGMN_5G_White_Paper_V1_0.pdf .

ONF. “OpenFlow Specification v1.2.” 2011.
https://www.opennetworking.org/images/stories/downloads/sdn-resources/onf-
specifications/openflow/openflow-spec-v1.2.pdf .

Ravindran, Ravi, Asit Chakraborti, and Aytac Azgin. “Forwarding Label Support in CCN Protocol.”
IETF/ICNRG. 21 March 2016. https://tools.ietf.org/html/draft-ravi-ccn-forwarding-label-02 .

Ravindran, Ravi, Xuan Liu, Asit Chakraborti, and G.Q Wang. “Towards Software-Defined ICN Based Edge
Cloud Services.” IEEE CloudNet. 2013.

Reed, M.J., M. Al-Naday, D. Trossen, G. Petropolous, and S. Spirou. “Stateless multicast switching in
software defined networks.” IEEE ICC. 2016.

Sifalakis, M., B. Kohler, C. Scherb, and C. Tschudin. “An information centric network for computing the
distribution of computations.” ACM ICN. Paris, France, 2014.
Sony and Tokyo Tech. “Sony and Tokyo Tech Jointly Develop Low-power LSIs for Wideband Millimeter-wave
Wireless Communications that Achieves the World’s Fastest Data Transfer Rate of 6.3 Gb/s - Low
power design specifically for use on mobile devices.” 20 Feb 2012.
http://www.sony.net/SonyInfo/News/Press/201202/12-0220E .
Suthar, Prakesh. “Deploying IN in LTE network and Options for 5G.” 2016.

Trossen, D., and G. Parisis. “Designing and Realizing an Information-Centric Internet.” IEEE Communications
Magazine 50, no. 7 (2012): 60-67.
Xylomenos, G., C. Ververidis, V. Siris, and et al. “A survey of information-centric networking research.” IEEE
Communication Surveys Tutorials 16, no. 2 (May 2014): 1024-1049.

10 Annex A: Proof-of-Concept Technical Background

10.1 End-to-end ICN Service Orchestration with Mobility for IMT 2020
10.1.1 System Architecture

Fig. 1 is the system level view of the PoC. ICN UEs connect to the ICN virtual service edge routers (VSERs) over
a single hop IP link (which can also be replaced with a WiFi or LTE access stack implementation). VSER runs
on COTS server and implements a CCN forwarding daemon along with the feature of enabling dynamic
interaction with any service function orchestrated by the service controllers on these nodes. Three kinds of
service functions are employed in our prototype: 1) to support basic network services like discovery and

274
