Page 152 - ITU-T Focus Group IMT-2020 Deliverables

3 ITU-T Focus Group IMT-2020 Deliverables

7.1.3 The basic procedure used for the exchange of information at the reference point

This subsection describes basic procedure used for the exchange of information at the reference point.
Figure 7.1-4 shows the procedure to exchange the “Virtual Resource Reservation (/ Complete)” message,
“Virtual Resource Release (/ Complete)” message: and “Virtual Resource Status Request (/ Status)” message:
as described in subsection 7.1.2.

Figure 7.1-4 – Procedure for the virtual resource reservation / release / status message
7.1.4 The list of the parameters included in information messages

In this subsection, the candidates of parameters included in the information messages at the reference point
are listed; the reference point is the point between the SEC and PRC as described in subsection 7.1.2. The list
of parameters and purposes are shown in Table 7.1-1.
The parameters are also considered in the document [Ref.7.1-4].

146
