5 Unleashing the potential of the Internet of Things

Appendix I

Use cases of networked vehicle services and applications using NGN

(This appendix does not form an integral part of this Recommendation.)

For the development of NGN capabilities and functional model to support networked vehicle
services and applications, it is useful to look at usage flows of networked vehicle services and
applications as well as to identify relevant mechanisms. In this regard, this appendix introduces
"Use cases of the networked vehicle" using the service configuration model, as shown in Figure I.1.

Networked vehicle
Service
platform
OEM Communication Vehicle related
devices platform services
Equipped Public telecom
end user NGN service (inc.GPS, etc.)
devices Multimedia
service
platform Enterprise services
Passenger
devices Private services
(inc.Home based
services)
Y.2281(11)_FI-1-App-I

Figure I.1 – Service configuration model of a networked vehicle

Taking into account the communication features and above service configuration model, following
classification of use cases can be derived as shown in Figure I.2.

Networked vehicle
Service
platform
OEM Communication Vehicle-related 1
devices platform services
8 Public telecom 2
Equipped service (inc.GPS, 3
devices Communication 2G/3G, etc.)
4 Multimedia
service networks
platform Enterprise services 5
4
Passenger Private services 6
MM devices (inc.Home-based
services) 7
Y.2281(11)_FI-2-App-I

Figure I.2 – Classification of use cases for communication of a networked vehicle

648 Rec. ITU-T Y.4407/Y.2281 (01/2011)
