ITU Journal on Future and Evolving Technologies, Volume 2 (2021), Issue 6

on the training SNR, we divide the target range of forward The training strategy for the encoder’s codeword and
SNRs into (small) non‑overlapping intervals and select a symbol power levels has been optimized empirically. The
single training SNR within each interval. levels are initialized to unit value, and kept constant for
Encoder and decoder are implemented as two separate a given number of epochs as early start of training pro‑
DNNs whose coef icients are determined through a joint duces codes with poor performance. On the other hand,
training procedure. The training procedure consists in if training of levels is started too late, they remain close to
the transmission of batches of randomly generated mes‑ their initial unit value, and therefore produce no bene its.
4
sages. The number of batches is 2 × 10 , where each It has been found empirically that starting to train code‑
3
batch contains 2 × 10 messages. DNN coef icients are word power levels at epoch 100 and symbol power levels
updated by an Adaptive Moment (ADAM) estimation opti‑ at epoch 200 provides the best results.
mizer based on the Binary Cross‑Entropy (BCE) loss func‑ As suggested in [1], it may be bene icial to perform train‑
tion. For each batch, a loss value is obtained by computing ing with longer messages compared to link level evalu‑
the BCE between the messages in that batch and the cor‑ ation as training with short messages does not produce
responding decoder outputs. The learning rate is initially good codes. According to our observations, training with
set to 0.02 and divided by 10 after the irst group of 10 3 longer messages, twice the length of LLS messages, is ben‑
batches. The gradient magnitude is clipped to 1. e icial. However, according to our observations, the ben‑
By monitoring the BCE loss value throughout the entire e it of using longer messages vanishes when training with
training session, we noticed that the loss trajectory has larger batches. Therefore, in our evaluations the length of
high peaks which appear more frequently during the ini‑ training messages and LLS messages is the same.
tialphasesof training. Thosepeaksindicatethatthetrain‑ The above training method produces codes with better
ing process is driving the encoder/decoder NNs away performance compared to the method of [1], as the per‑
from their optimal performances. In order to mitigate the formance evaluations of Section 4 will show. Training pa‑
detrimental effect of the above events, the following coun‑ rameters are summarized in Table 3.
termeasures have been taken:
4. PERFORMANCE EVALUATIONS
• usage of a larger batch size, 10 times larger than [1].
1
Usage of large batches stabilizes training and ac‑ In this section, we assess the BLER performance of DEF
celerates convergence of NN weights towards values codes and compare their performance with the perfor‑
that produce good performance; mance of the NR LDPC code reported in [12] and the per‑
formance of Deepcode [1] for the same Spectral Ef iciency
• implementation of a training roll‑back mechanism (SE). The SE is de ined as the ratio of the number of infor‑
that discards the NN weight updates of the last epoch mation bits over the number of forward‑channel time‑
if the loss value produced by the NNs with updated frequency resources used for transmission of the corre‑
weights is at least 10 times larger than the loss pro‑ sponding codeword. As each time‑frequency resource
duced by the NNs with previous weights. carries a complex symbol, and since each complex symbol
is produced by combining two consecutive real symbols,
As we observed that the outcome of training is sensitive to we have
the random number generators’ initialization, each train‑
ing is repeated three times with different initialization ≜ 1 + [bits/s/Hz]. (32)
seeds. For each repetition, we record the inal NN weights
and the NN weights that produced the smallest loss dur‑ The forward‑channel and feedback‑channel impairments
ing training. After training, Link‑Level Simulations (LLS) are modeled as AWGN with variance 2 = 1/ and
are performed using all the recorded weights. The set of 2 = 1/ , respectively. The training forward
weights that provides the lowest Block Error Rate (BLER) SNR and LLS forward SNR are the same; the feedback
is kept and the others are discarded. channel is noiseless.
As described in Subsection 2.3 and illustrated in Fig. 2, the The set of parameters used in the performance evaluations
PSG output is normalized so that each coded symbol has is shown in Table 4. For DEF code performance evaluations,
zero mean and unit variance. During NN training, normal‑ we show that even the shortest feedback extensions –
ization subtracts the batch mean from the PSG output and corresponding to the and parameters of Table 4
divides the result of subtraction by the batch standard de‑
viation. After training, encoder calibration is performed in Table 3 – Training parameters.
order to compute the mean and the variance of the RNN Training parameter Value
outputs over a given number of codewords. Calibration
6
is done over 10 codewords in the simulations here re‑ Number of epochs 2000
ported. In LLS, normalization is done using the mean and Number of batches per epoch 10
variance values computed during calibration. Number of codewords per batch 2000
1 By training stabilization we mean that the loss function produces Training message length [bits] 50
smoother trajectories during training.
Starting epoch for codeword‑level weights training 100
Starting epoch for symbol‑level weights training 200
