Video processing and storage                                       4


            5       Conventions

            In this Recommendation:
            –       The keywords "is required to" indicate a requirement which must be strictly followed and from
                    which no deviation is permitted if conformance to this Recommendation is to be claimed.
            –       The keywords "is recommended" indicate a requirement which is recommended but which is not
                    absolutely required. Thus this requirement need not be present to claim conformance.

            6       Scenarios

            This  clause  describes  typical  scenarios  illustrating  the  cloud  computing  platform  supporting  visual
            surveillance and deriving its service requirements.

            6.1     Video distribution
            The cloud computing platform in a visual surveillance (VS) system can support large-scale real-time video
            forwarding. For example, many surveillance cameras are deployed in the Great Wall Scenic Area, and the
            remote monitoring function of the cameras is open to the public. If users wants to see current images of the
            Great Wall remotely, they can view the network video information on their local devices through the cloud-
            based real-time video distribution function.
            Step 1: Users enter the customer unit (CU) which supports remote live video viewing of the Great Wall Scenic
            Area, and submit their request to the VS system.
            Step  2:  After  receiving  a  video-viewing  request,  the  VS  system  authenticates  the  user  information,  and
            obtains  the  related  information  from  a  video-forwarding  function  unit  that  is  deployed  on  the  cloud
            computing platform. The cloud computing platform can dynamically create or destroy the video-forwarding
            function according to current user requests. The VS system then responds to the CU with the information
            about the video-forwarding function on the cloud computing platform.

            Step 3: After receiving the VS system response, the CU sends a video-viewing request to the cloud computing
            platform.

            Step 4: The cloud computing platform obtains the video stream from the corresponding camera, and then
            forwards the video stream to the CU.

            6.2     Video transcoding

            The  cloud  computing  platform  in  a  VS  system  can  support  video-transcoding  functions,  e.g.,  code  rate
            transformation and video format conversion. The traffic department of a city has deployed a large-scale VS
            system  in  the  city  streets  with  high-definition  network  cameras.  Users  want  to  view  the  current  traffic
            situation on their way home with their mobile phones. Due to the limited bandwidth of mobile devices and
            mobile data traffic limits, high-definition surveillance video needs to be transcoded to low-resolution video
            before forwarding to the CU. The video-transcoding operation can be carried out on the cloud computing
            platform.

            Step 1: Users log into the VS system via their mobile customer unit (MCU), and select the appropriate network
            camera. The MCU then sends a video-viewing request to the VS system with the video format description.

            Step 2: After receiving the video-viewing request, the VS system authenticates the user information, and
            obtains  the  related  information  from  a  video-forwarding  function  unit  that  is  deployed  on  the  cloud
            computing  platform.  The  VS  system  then  responds  to  the  MCU  with  the  information  from  the  video-
            forwarding function in the cloud computing platform.
            Step 3: After receiving the response of the VS system, the MCU sends a video-viewing request to the cloud
            computing platform.
            Step  4: The  cloud  computing  platform obtains  the video  stream  from  the corresponding  camera.  Then,
            according to the video format description of the MCU, the surveillance video stream is transcoded by the
            video-transcoding component deployed in the cloud computing platform. The cloud computing platform can
