Page 746 - Cloud computing: From paradigm to operation

XaaS 3

Figure 6 – Relationship among CSC, CSP and CSN

CSP and CSN have their own security requirements about the environment in different levels of SaaS. Table
2 illustrates the security requirements of CSP and CSN in the SaaS application environment. The requirements
applicable for both CSP and CSN are the common requirements.

Table 2 – Security requirements of CSP and CSN in SaaS application environment

SaaS application environment
Common Identity and access management, data security, security assessment and audit, interface security,
requirements security hardening.
Availability, service interoperability/portability guarantee, software assets protection, legal
CSP
compliance, security verification for source codes.
CSN Audit security, software security, software maintainability.

8.1 Common security requirements

For both CSP and CSN, they have several common security requirements in the SaaS application environment.
8.1.1 Identity and access management (IAM)

8.1.1.1 Identity management (IdM)
Multiple administrators and users are involved in the SaaS application environment, which can be accessed
to and used internally (CSPs) and externally (CSNs). Identity Management (IdM) is needed not only to protect
identities, but also to facilitate access management, authentication, authorization and transaction audit
processes in such a dynamic and open SaaS application environment.

For all maturity models, IdM should enable the implementation of single sign-on and/or identity federation
for the SaaS application environment using varied authentication mechanisms in different security domains.

8.1.1.2 Trust model

The SaaS application environment is required to incorporate an overall trust model for both multi-tenant
level and scalable level. This trust model will enable the creation of islands and/or federations of trusted
entities. Consequently, the SaaS application environment management system, the underlying resources,
hypervisors, virtual machines and applications built upon the SaaS application environment will be able to
authenticate the identities and authorized rights of other entities and components. Each island or federation
of trust will be based on one or more trusted authorities (e.g., a public key infrastructure (PKI) certificate
authority).
