3                                                       XaaS


            8.3.4.3    CCS policy management

            The CCS policy management functional component provides capabilities for defining, storing and retrieving
            policies (e.g., quotas) that apply to virtual resources for cloud compute and storage. Policies can include
            technical and security policies that apply to these virtual resources and their usage by their users.

            8.3.4.4    CCS service level management
            The CCS service level management functional component provides capabilities for managing the service
            levels of virtual resources for cloud compute and storage, aiming to ensure that each virtual resource meets
            the negotiated service level requirements.
            The CCS service level management functional component manages the capacity and performance relating to
            virtual resources for cloud compute and storage. This can involve the application of policies (e.g., a placement
            deployment rule which aims to avoid single points of failure).
            The  CCS  service  level  management  functional  component  obtains  monitoring  information  from  the  CCS
            monitoring and reporting functional component in order to measure and record KPIs for the virtual resources.
            Capacity of virtual resources is allocated or de-allocated based on the basis of these KPIs.
            The CCS service level management functional component also keeps track of the overall state of allocated
            and  available  resources  for  cloud  compute  and  storage.  The  comparison  of  allocated  capacity  against
            performance KPIs can assist in the identification of current or potential bottlenecks, in support of capacity
            planning. This includes the management of the virtual resources capacity (e.g., density of virtual resources
            to physical resources), and the forwarding of information related to infrastructure resources capacity and
            usage reporting.
            8.3.4.5    CCS incident and problem management

            The  CCS  incident  and  problem  management  functional  component  provides  capabilities  for  capturing
            incident or problem reports related to virtual resources for CCS and managing those reports through to
            resolution.

            8.3.4.6    Virtualization management
            The  virtualization  management  functional  component  provides  the  capabilities  for  managing  the
            virtualization of the resources for CCS (e.g., realized by means of hypervisors).
            8.3.4.7    CCS virtual resource inventory
            The CCS virtual resource inventory functional component keeps track of the allocation of virtual resources
            for CCS to physical resources (e.g., server pool).

            8.3.4.8    Software image management
            The software image management functional component manages software images (e.g., network functions)
            as requested by other OSS functional components (e.g., OSS for network functions). These requests include
            operations  on  images  such  as  add,  delete,  update,  query  and  perform  rollback.  Once  validated  by  the
            software  image  management  functional  component,  software  images  are  stored  in  a  software  image
            repository.
            8.3.5   OSS-NC functional components
            NOTE – The following description is based on an adaptation of the OSS functional components as described in clause
            9.2.5.3 of [ITU-T Y.3502].
            The OSS-NC functional components encompass the set of operational related management capabilities that
            are required in order to manage and control the network connectivity in NaaS CSP domains, also called NaaS
            CSP connectivity domains. See clause 7.8.4 for a description of the OSS-NC functionalities.

            The OSS-NC functional components may be able to manage network connectivity across one or multiple NaaS
            CSP's domains (e.g., access, backhaul or core NaaS CSP domains) and can also manage network connectivity
            at one or multiple technology layers (e.g., overlay, IP, multiprotocol label switching (MPLS), optical transport
            network (OTN)).
