3                                                       XaaS


            8.2.2   Administration capabilities (NaaS)

            The administration capabilities (NaaS) functional component provides a set of capabilities for accessing the
            OSS-NaaS functionalities (see clause 7.8.1) related to the management of instantiated NaaS services. This
            includes  functionalities  contained  within  the  OSS-NaaS  functional  components.  For  example,  the
            administration capabilities (NaaS) functional component allows the NaaS CSC to view performance and fault
            information related to instantiated NaaS services. The NaaS CSP will collect information requested by the
            NaaS CSC and make it available through reporting to the NaaS CSC via the administration capabilities (NaaS)
            functional component.
            8.2.3   Service capabilities (NaaS)

            The  service  capabilities  (NaaS)  functional  component  consists  of  the  necessary  software  required  to
            implement the NaaS service offered to the NaaS CSC and implements the functionality defined by the NaaS
            service interface, i.e., the interface offered to the NaaS CSC, independent of the service implementation.

            As shown in Figure 8-2, the service capabilities (NaaS) functional component provides capabilities exposed
            to the NaaS CSC according to the NaaS service model and NaaS service operational policy model selected by
            the NaaS CSC through business level interactions with the NaaS CSP. Refer to clause 8.3.1 for the description
            of these two NaaS-related service models.
            Using the NaaS service exposed API provided by the service capabilities (NaaS) functional component, the
            NaaS CSC can trigger NaaS service specific on-demand behaviours (made possible by the NaaS CSP according
            to the selected NaaS service model). These on-demand requests are validated by the NaaS CSP according to
            the NaaS service specific policies that govern such on-demand behaviour. The on-demand behaviours (and
            associated constraints) are defined in the NaaS service operational policy model selected by the NaaS CSC at
            NaaS instantiation time. For example, a NaaS service operational policy model may describe the range of
            bandwidth in which the NaaS CSC is permitted to send traffic to the NaaS CSP or the range of computing
            resources that a specific NF instance is allowed to be allocated in the NaaS CSP infrastructure.

            8.3     OSS functional components

            The OSSs functional components encompass the set of operational-related management capabilities of the
            NaaS functional architecture in order to manage and control aspects from NaaS services down to the NaaS
            CSP  infrastructure  resources  including  cloud  compute  and  storage,  network  connectivity  and  physical
            resources.
            The OSS components described in this clause are intended to support the functionalities for an evolved real-
            time OSS described in clause 7.8. The description of OSS components follows the structure of the OSS as
            shown in Figure 7-1.

            Annex A describes reference points related to OSS functional components.

            8.3.1   OSS-NaaS functional components
            The OSS-NaaS functional components encompass the set of operational-related management functionalities
            that are required in order to manage and control NaaS services offered to customers (refer to clause 7.8.1).
            NOTE – These functional components are not meant to be specific to NaaS and are applicable to other cloud service
            categories provided by NaaS CSPs.

            Figure 8-3 shows the OSS-NaaS functional components.
















            680
