3                                                       XaaS


            the NaaS CSC. This representation avoids the direct communication and interaction between the NaaS CSC
            and these NaaS resources (e.g., network elements of the NaaS CSP infrastructure) and masks implementation
            specific  aspects  of  NaaS  resources  used  in  the  context  of  the  NaaS  service  instance.  This  abstract  view
            presented to the NaaS CSC also allows real-time configuration change demands from the NaaS CSC to be
            reflected by the NaaS CSP on its own resources. Therefore, a hierarchical and extensible framework, which
            can be realised by a set of information models, needs to be designed to hide the protocol specific and/or
            vendor specific details of the resources being used by the NaaS CSP. The modelled objects being part of these
            NaaS information models can be grouped as NaaS resource model, NaaS service model, and NaaS service
            operational policy model.
            NaaS  resource  models  reflect  in  an  abstract  manner  NaaS  CSP's  resources  including  their  associated
            topological view across different layers (e.g., layer 2 (L2) and layer 3 (L3)). NaaS resource models designed by
            the NaaS CSP or cloud service partners (CSNs) (e.g., service developer) are used by the NaaS CSP to represent
            NaaS CSP's resources at a conceptual level, including physical and/or virtualized network functions as well as
            connectivity links. NaaS resource models are not exposed to the NaaS CSC.
            A NaaS service model is service specific, i.e., specific to the NaaS service being offered to the NaaS CSC by the
            NaaS CSP but rely on underlying NaaS resource models. Once a NaaS service is instantiated for a NaaS CSC,
            the corresponding NaaS service model designed by the NaaS CSP is exposed to the NaaS CSC.
            A NaaS service operational policy model is service specific, i.e., are specific to the NaaS service being offered
            to the NaaS CSC. This model defines NaaS CSP-wide policies applicable for the corresponding NaaS service
            and is designed by the NaaS CSP or CSN (e.g., service developer). During the instantiation of a NaaS service,
            the NaaS service operational policy model is combined with the NaaS service model and mapped into a target
            configuration of NaaS CSP's resources (e.g., network elements), according to NaaS resource models.
            NOTE – The usage example of modelling is provided in Appendix II.

            7.3     Functionalities for NaaS service orchestration
            The NaaS service orchestration functionalities are responsible for cross-domain service orchestration within
            the NaaS CSP, e.g., for a NaaS connectivity service, the functionality will be capable to orchestrate NaaS
            resources  (including  network  services,  network  functions  and  resources)  in  multiple  NaaS  CSP  domains
            (including legacy domains and virtualized network domains).
            Upon  receipt  of  a  NaaS  service  request  from  the  NaaS  CSC,  these  functionalities  are  responsible  for
            decomposing, as necessary, the request into several independent requests and for distributing each of the
            resulting requests to the relevant control functions of the NaaS CSP. An example of a composite NaaS service
            is a service chain path, i.e., an ordered list of connection points forming a chain of network functions (PNFs
            and/or VNFs), along with policies associated to the list.
            The NaaS service orchestration functionalities interact with the NaaS service instantiation functionalities to
            address NaaS service decomposition and configuration of requests received from NaaS service instantiation
            functionalities (see clause 7.2.1).

            In case of a non-composite NaaS service request received from the NaaS CSC, the NaaS service orchestration
            functionalities can transfer this request to the relevant domain control function.
            The NaaS orchestration functionalities are also responsible for ensuring that NaaS resources (e.g., NSs, NFs,
            connectivity) are appropriately instantiated throughout the different NaaS CSP domains (e.g., across one or
            network domains that can be using different networking connectivity technologies).


            7.4     Functionalities for network analytics
            Functionalities  for  network  analytics  are  responsible  for  data  collection  from  the  NaaS  CSP's  network
            environment (such as network jitter, delay, packet loss rate, round-trip time, domain name system (DNS)
            resolution time) and events listening to continuously monitor NaaS services during their lifecycle. These
            functionalities help to provide customized analytical network applications and provide the analysed results
            to the related functional components (such as resource abstraction and control) for further action, including
            healing  the  service,  appropriately  scale  up  or  scale  down  the  service,  dynamically  adjust  routing,  etc.


            672
