XaaS                                                     3


            9.2     Virtual desktop connection and delivery functions

            The VDCD-FS comprise DPP-F, UAM-F, CCM-F, and PA-F as shown in Figure 9-2. The VDCD-FS have three
            interfaces  with  other  functional  groups  such  as  CS-FS,  virtual  desktop  resource  management  functions
            (VDRM-FS), and virtualization infrastructure functions (VI-FS).






















































                                   Figure 9-2 – Functions and reference points in VDCD-FS
            9.2.1   Delivery protocol processing function

            The DPP-F delivers the exchanged information to the SC-F through I_SC_DPP. The DPP-F communicates to
            the CN-F and the CPC-F to perform the connection negotiation and peripheral event through I_CN_DP and
            ICP_DP, respectively. Virtual desktop access information from the CCM_F on I_DP_CCM is forwarded to VI-FS
            through I_DPP_IAM. A detailed functional description for the DPP-F is specified in clause 7.2.1.
            9.2.2   User access management function

            For user authentication, the UAM-F validates a DaaS user with CSU's access information through I_SC_UAM
            and connects the user account and profile management function (UAPM-F) through I_UAM_UAPM with
            CSU's access information and CSU's account information. A detailed functional description for the UAM-F is
            specified in clause 7.2.3.

            9.2.3   Client connection management function
            The  CCM-F  delivers  and  verifies  virtual  desktop  access  information  to  CS-FS  through  I_SC_CCM.  Virtual
            desktop access information from the SC-F is transferred to the DPP-F through I_DP_CCM. The CCM-F also

                                                                                                         595
