Page 1003 - Cloud computing: From paradigm to operation

Security 7

SaaS Software as a Service

SIM Subscriber Identity Module
SLA Service Level Agreement

VM Virtual Machine

5 Conventions
In this Recommendation:
The keywords "is required to" indicate a requirement which must be strictly followed and from which no
deviation is permitted, if conformance to this Recommendation is to be claimed.

The keywords "is recommended" indicate a requirement which is recommended but which is not absolutely
required. Thus, this requirement need not be present to claim conformance.

The keywords "is prohibited from" indicate a requirement which must be strictly followed and from which
no deviation is permitted, if conformance to this Recommendation is to be claimed.

The keywords "can optionally" indicate an optional requirement which is permissible, without implying any
sense of being recommended. This term is not intended to imply that the vendor's implementation must
provide the option, and the feature can be optionally enabled by the network operator/service provider.
Rather, it means the vendor may optionally provide the feature and still claim conformance with the
specification.

6 Overview

This Recommendation analyses data security requirements for the monitoring service of cloud computing
including monitoring data scope, monitoring data lifecycle, security threats and challenges, and monitoring
data security requirements of cloud computing.

Monitoring data scope describes two types of cloud monitoring data: necessary and optional, and also
explains the use cases.

Monitoring data lifecycle, and the security threats and challenges, describe the content and security threats
and challenges of cloud monitoring data collection, storage, use, migration, analysis, presentation,
destruction and backup.

Monitoring data security requirements describes the detailed requirements for each lifecycle stage of cloud
monitoring data.

7 Scope of monitoring data for cloud computing

In a cloud computing environment, there are two types of monitoring data: necessary monitoring data and
optional monitoring data.

Necessary monitoring data is that which is used to maintain service level agreements (SLAs). Necessary
monitoring data can help the CSP run the cloud computing platform securely and stably. Necessary
monitoring data may include, but is not limited to, management system monitoring data, physical resources
monitoring data and network monitoring data. Necessary monitoring data is mainly used by CSPs but could
also be shared with CSCs.
Optional monitoring data is that which is provided at the request of the CSC to provide the monitoring service
by the CSP. Optional monitoring data may include, but is not be limited to, virtual machine monitoring data,
data storage service monitoring data and the CSCs' data associated with the monitoring of their own
application on cloud.

995
