5 Big data - Concept and application for telecommunications

Appendix II

Comparison analysis between cloud computing and data storage federation
(This appendix does not form an integral part of this Recommendation.)

Table II.1 shows the mapping between data storage federation ecosystem and the CCRA user view. The DSF
service customer has two sub-roles and these sub-roles are mapped onto the CSC:cloud service user because
two sub-roles have a relationship of using service. The DSF local storage provider and CSP:cloud service
manager and CSP:cloud service operations manager, which provide data storage, are mapped in the
perspective of providing service. However, for the DSF service provider, the additional considerations in data
storage perspective are needed in cloud computing. To federate and provide data storage from DSF local
storages, such as cloud storage and non-cloud storage, they are properly described in CSP as new sub-roles,
activities and involvements.

Table II.1 – Mapping between data storage federation ecosystem and CCRA user view

ITU-T Y.3505 ITU-T Y.3502
(DSF) (Cloud computing)
Note
Roles Activities Sub-roles Activities

DSF service • use DSF CSC:cloud • use cloud service • The additional
customer service service user considerations in data
storage and data
perspective on the
federated storage
environment are needed.
DSF service • provide – – • The additional
provider virtual considerations in data
storage pool storage perspective are
• provide needed as sub-roles and
single virtual activities in CSP.
volume • The sub-roles and activities
• manage support the data storage
storage federation service.
management
metadata
• manage data
storage
policy
• manipulate – – • The additional
DSF data considerations in data
• manage data storage perspective are
operation needed as sub-roles and
metadata activities in CSP.
• manage data • The sub-roles and activities
manipulation support the data storage
policy federation service.
DSF local storage • provide DSF CSP:cloud • provide services e • Activities and their
provider local storage service involvements of the two
manager sub-roles in ITU-T Y.3502
are supported to provide
cloud data storage.

280 Network and infrastructure
