5                                Big data - Concept and application for telecommunications



                    bDDN is supposed to collect all the information that is related to network business and status, while
                    at the same time fulfilling the mission of storage, classification and analysation.

            10.1.2  Network big data repository capabilities
            1)      Capability of network big data storage
                    The network contains a variety of a large amount of data; bDDN needs to provide all kinds of large
                    data storage capabilities, including a mass-structured data storage capability and an unstructured
                    data storage capability.

            2)      Capability of big data interchanging and sharing
                    Different  network  management  realms  are  supposed  to  be  capable  of  big  data  sharing  and
                    exchanging, so that big data resources can be utilized by different realms or network services.
            10.1.3  Network big data analyser layer capabilities
            1)      Capability of correlation analysis
                    A big-data-driven network analyser conforms to the traditional big data paradigm: comprehensive
                    data outweighs sampled data, correlation rather than causality. It is difficult for a network designer
                    or operator to find and compute the network causality. The correlations learned from network plane
                    data and management plane data can be utilised to effectively improve network resource allocation,
                    reduce CAPEX and OPEX, and maximize revenue.
            2)      Capability of big data real-time computing and analysing

                    Considering the huge amount and fast changing characteristics of network data, bDDN is required
                    to  provide  real-time  analysing  ability.  bDDN  would  perform  comprehensive  data  fusing  and
                    analysing over the collected information, correlate various influencing factors and network status,
                    and find out the causality and logistics behind them by using big data technologies.
            3)      Capability of machine learning and deep learning
                    The network big data analyser layer is the core component of the big data plane. It will take the
                    machine learning and deep learning on the huge data collected by big data sensing layer, to achieve
                    network  perception  and  cognition,  including  network  autonomous  optimization,  autonomous
                    adjustment, intelligent fault location and a series of network intelligence goals.
            4)      Capability of network QoS anomaly detection and root cause tracking
                    Different  applications  have  different  QoS  parameter  requirements,  for  example,  delay/latency,
                    jitter, round trip time, etc. Network QoS anomaly means network QoS parameters anomaly. To meet
                    the complex QoS/QoE requirements of different applications/services, the networks are required to
                    detect the network QoS anomaly and track the root cause of the anomaly. The bDDN should have
                    the capability to automatically monitor the network QoS anomalies and track the root causes of the
                    anomalies. The problems of network performance anomalies are network data, such as, network
                    traffic data, syslog data and management data, etc. The QoS anomaly network data is from network
                    anomaly  events,  such  as,  network  attacks,  protocol  bugs  and  link  up/down,  etc.  Based  on  the
                    analysis of multilayer dependence and spatial-temporal dependence of network data and network
                    events, bDDN can reversely track the root causes of network anomalies. The bDDN is able to clarify
                    the positive correlations and reverse tracking mechanisms of network 'anomaly events – anomaly
                    data – network anomalies'.

            10.1.4  Data intelligence and service layer capabilities
            1)      Capability of big data visualization
                    The network data visualization is a visual representation of the insights gained from the network
                    data  analyser.  A  network data visualization  capability may  reveal  the  hidden potential value of
                    comprehensive network data. Network data visualization exhibits the correlations and implications
                    of raw network plane and management plane data with images, tables, graphs, charts, diagrams
                    and maps etc., so that network operators can see and understand the connections in a real network.



            192      Network and infrastructure
