            6.2.3   Network function descriptions

            6.2.3.1    Control plane network functions
            NSSF (Network Slice Selection Function)

            •       Selects core network slice instance to accommodate the UE.
            NOTE – It is assumed that UE can indicate required network slice type to the core network and then the core
            network selects a particular network slice instance for the UE. Further clarifications on how UE and CN
            interact to select a NSI are required.

            MMCF (Mobility Management Control Function)
            •       Provides mobility support, including session continuity, for UEs connected to IMT-2020 core via
                    mobile and/or fixed access networks.

                    –   When a UE is simultaneously connected to the same core network over heterogeneous access
                        networks, the UE is served by a single MMCF via interworking function (IWF).
            •       Performs access specific mobility control, e.g. UE reachability management, mobility restriction, etc.

            •       Performs access common mobility control, e.g. UE registration and location management, etc.
            •       Routes  NAS  (Non-Access  Stratum)  signalling  messages  (e.g.,  session  management  related)  to
                    corresponding session management control function.

                    –   A UE with multiple established PDU sessions may be served by different instances of SMCF. The
                        MMCF  selects  the  SMCF  functions  for  the  PDU  sessions. MMCF may  select  different  SMCF
                        instances for different PDU sessions.
            •       Terminates RAN-CP interface and NAS (including ciphering and integrity protection)
            •       Access Authentication

            SMCF (Session Management Control Function)
            •       Responsible for the setup of the IP or non-IP traffic connectivity (i.e. PUD session) for the UE as well
                    as controlling the user plane for that connectivity (e.g., selection/re-selection of user plane network
                    functions and user path, enforcement of policy and charging rules, etc.).

                    –   Multiple SMCF can serve one UE in a network slice instance, e.g. to support different data
                        networks.
                    –   Data plane network functions are selected/re-selected based on UE location, UE subscription
                        profile, session and service continuity mode selected for the PDU session, data network, user
                        plane network function load distribution, etc.
            •       Allocates UE IP address (including optional authorization).
            •       Provides session continuity with respect to UE mobility.
            •       Terminates session management related NAS messages
            •       Initiates access network specific session management information

                    –   When SMCF needs to send NAS session management signalling to a UE, it provides information
                        allowing the MMCF to retrieve the corresponding UE NAS signalling context.
            •       Handles policy and charging rules

            UACF (Unified Authentication Control Function)
            •       Responsible  for  the  authentication  of  the  identity  (e.g.,  user  identity)  that  is  presented  to  the
                    network, when a UE requests to receive service(s) from the network and network slices.
            SIDB (Subscriber Information DB function)
            •       Provides and manages user subscription data, policy data (e.g., on QoS and charging), session/user
                    related context and state.
