2 Use Case Description

2�1 Description

The semiconductor industry faces significant challenges due to rapidly expanding SoC
demand, workforce shortages, and labor-intensive design processes[3]. Traditional physical
design methods often require weeks or months of effort from specialized engineers, creating
bottlenecks in production pipelines. As system semiconductor complexity increases,
conventional approaches struggle to scale effectively, threatening competitiveness in a fast-
moving market.

This use case aims to revolutionize semiconductor design by automating critical physical design
steps that currently rely on extensive manual intervention. It leverages Reinforcement Learning
(RL) for its effectiveness in navigating complex, high-dimensional design spaces and identifying
optimal solutions for semiconductor physical layout optimization[4].

Specific objectives include:
• Shortening design time from weeks/months to hours.
• Reducing human error in complex layout decisions.
• Alleviating workforce constraints in specialized design roles.
• Enabling teams to handle more intricate layouts (hundreds of macro cells, thousands of
standard cells).
• Fostering a more resilient design ecosystem, promoting innovation and broader access
to advanced techniques.

The solution leverages RL-based artificial intelligence to optimize semiconductor physical
design processes. Key technical components include:

• RL algorithms that learn optimal placement strategies for large-scale chip layouts
• Metadata Transformation Modules to protect sensitive design information
• Integration Layers ensuring seamless compatibility with existing design flows and tools

Proven Performance

Initial deployments at partner companies yielded highly positive customer feedback,
demonstrating significant design cycle reductions. An average optimization benefit of
approximately 19% was observed. Specifically, for high-density designs, overall duration
decreased by 20%, and the floor planning stage saw a remarkable 76% reduction, cutting
design time from over a week to roughly one day.

Broad Applicability & Future Direction

The AI-based floor planning solution is versatile, applicable across various designs by utilizing
physical data from LEF/DEF files, rather than being limited by specific architectural types like
RISC/CISC. Its AI focuses on universal optimization goals like minimizing wire lengths and
congestion. Additionally, plans are underway to open-source the RL model and UI components,
with the detailed scope depending on ongoing research and market demand.

This approach addresses immediate market pressures for production efficiency and long-
term strategic needs, including talent shortages and technological advancement in the
