Cloud Computing management 2
I.4 Composite applications or mash-ups use case
Title Composite applications or mash-ups use case
Description CSP1 builds cloud service c1 as composite apps, or mash-ups from service1 delivered by CSP1
and sevice2 delivered by CSP2.
Roles CSP
Figure (optional)
Pre-conditions – Service1 delivered by CSP1.
(optional) – Service2 delivered by CSP2.
Post-conditions – A composite service c1 is built from service1 and service2.
(optional)
Derived – Composite applications or mash-ups (refer to clause 7.5)
requirements
I.5 Traditional business processes use case
Title Traditional business processes use case
Description CSP1 builds a composite service c1 from service1 delivered by CSP1 and sevice2 delivered by
CSP2. CSP1 can provide functions to support the application of traditional business processes
associated with administration, provisioning/configuration, service assurance and charging
/billing/settlement for service c1.
Roles CSP
Figure (optional)
Pre-conditions – CSP1 builds a composite service c1 from service1 delivered by CSP1 and sevice2 delivered
(optional) by CSP2.
Post-conditions – CSP1 can provide functions to support the application of traditional business processes
(optional) associated with administration, provisioning/configuration, service assurance and charging
/billing/settlement for service c1.
Derived – Traditional business processes (refer to clause 7.6)
requirements
