2021 ITU Kaleidoscope Academic Conference




           channel estimation according to the  delay spread  of the   2.1   Frequency domain fading factor
           wireless channel multipath, and then improve the receiving
           performance. If the base station can distinguish the different   The time dispersion and frequency domain selective fading
           speeds, the period of the uplink Sounding Reference Signal   of  the wireless  channel are all produced by the
           (SRS) can be  adapted  according to the user’s  speed. The   superposition of  multipath  signals  with different  time
           Demodulation  Reference  Signal  (DMRS) also can adjust   delays. The two effects exist at the same time, the time
           adaptively the number of pilots according to the speed. The   dispersion  is  reflected  in  the  time  domain,  and  the
           recognition of  LOS/NLOS  channel scenarios can be used   frequency selective  fading  is reflected in the  frequency
           for positioning or as a priority  reference for  Multi-User   domain. The frequency selective fading is to filter the
           Multiple-Input Multiple-Output (MU-MIMO) user pairing.   transmitted signal, and the different frequency components
           Then  this  paper  mainly  studies  the  wireless  channel   of the signal  have  different fading amplitudes.  When  the
           scenario  recognition  in 4G  or  5G dense  urban areas and   transmitted signal  bandwidth is narrow enough,  all
           rural  or  suburban areas.  The  neural network  is used  to   frequency components almost experience the same fading,
           realize wireless channel scenario  recognition. The main   and which  is  non-frequency  selective  fading.  When  the
           contributions are summarized as follows:           signal bandwidth is relatively large, the different frequency
                                                              components have  different  attenuation coefficients,  which
           1. Extract key wireless channel characteristics, including   is frequency selective fading.
           frequency domain fading  characteristic, multipath power
           delay distribution,  channel  peak response ratio  in  time   In  this  paper, the power variance  of the channel impulse
           domain and time correlation characteristics.  These   response in the frequency domain is used to characterize the
           characteristics  are  easy  to  calculate,  which  has  high   frequency selective fading.  Assuming that in the  5G NR
           engineering application value.                     system, the transmitted signal occupies N RB  resource blocks
                                                              in  the frequency domain. After the channel estimation  in
           2. Propose  a wireless channel scenario  recognition   the receiver, the  CIR  on subcarrier k at the moment t is
           framework based on neural networks, which can not only   h(k, t). There are 6 pilot subcarriers on one Resource Block
           distinguish LOS/NLOS scenarios, but also identify different   (RB), and  then  the signal power  on  resource block RB  at
           speeds and different multipath delay spreads.      the moment t is calculated by Equation (1).   i

           3.  The performance of the  traditional threshold algorithm    P(RB , t) = ∑ 5  |h(k, t)|                   (1)
                                                                                    1
                                                                                               2
           and the neural network  classifier is compared, and the            i     6  k=0
           recognition  results  of  the neural network  classifier under
           different channel  feature composition structures and   At the momentt, the average power  of the signal  on the
           different Signal-to-Noise Ratio (SNR) are given.   occupied frequency domain bandwidth is  calculated by
                                                              Equation (2).
                   2.  WIRELESS CHANNEL FEATURE
                               EXTRACTION                                 P �(t) =  1  ∑ N RB −1 P(RB , t)                 (2)
                                                                                              i
                                                                                N RB  RB i =0
           As mentioned in  Section  1, the  receiving algorithm can   At  the  moment t ,  the  normalized power variance  is
           make adaptive adjustments based on the identified wireless   calculated by Equation (3).
           channels to improve system  performance. The wireless
           channel scenarios that are mainly studied and distinguished     1   N RB −1             2
                                                                                                    �
           in this paper are: (1) LOS or NLOS, (2) Different speeds:   δ(t) =  N RB  ∑ RB i =0 �P(RB , t) − P �(t)� P �(t)  (3)
                                                                                         i
           low speed, medium speed and  high speed, (3)  Multipath
           delay spread: low and high.                        2.2   Multipath power delay distribution
           Choosing information-rich,  discriminative features is the   Time dispersion and frequency  domain selective fading
           key to an effective classification algorithm. In this section,   exist simultaneously. The  frequency domain feature  is
           Channel  Impulse Response (CIR) is  used to calculate   extracted in Section 2.1, and the time dispersion feature is
           wireless channel characteristics. Because only LOS/NLOS,   extracted  in  this  section.  Time  dispersion  is  usually
           different  multipath delay spread  and different  speeds  are   characterized by  the  average delay  spread and the  root
           distinguished in this paper, there is no distinction in spatial   mean square delay, as in [11] and [13]. However, in order
           dimension, so we choose frequency domain fading factor δ,   to obtain the average delay spread and the root mean square
           multipath power  delay distribution P,  channel  power peak   delay, it is necessary to estimate accurately the delay and
           response ratio  γ  in  the  time domain, channel  time   the  power of  each propagation path,  and  which  is a
           correlation value β and its angle φ as the wireless channel   challenge for a commercial communication system. In this
           characteristics; the characteristic set of the wireless channel   paper, a multipath  power  delay distribution is calculated
           can be  defined  as χ = [δ, P, γ, β, φ, y] , where  y is  the   based on the CIR in the time domain. There is no need to
           classification label of the wireless channel scenario.   separate each propagation path, which  reduces the
                                                              complexity of implementation.







                                                          – 126 –
