ITU Journal on Future and Evolving Technologies, Volume 2 (2021), Issue 2




          considered the same with our Design 2. TX digital BF is  for P ≥ 15dBm, this design is incapable of guarantee‑

          designed for SI minimization from the TX side, whereas  ing residual SI power levels at any of the RX RF chains be‑
          RX digital BF is given by U , as described in Section 5.  low the required    = −60dBm. Figs. 4a and 4b demon‑
                                                                               A

          Design 5: SotA with 0 taps/0 AUXTX. This is the SoftNull  strate that the proposed multi‑tap‑based design ensures
          method presented in [7] that does not adopt analog can‑  that the residual SI power satis ies the    constraint for all
                                                                                                A
          cellation, relying solely on TX digital BF to reduce SI at the  considered TX powers for    = 4 and    = 8 taps, which
          RX antennas of node   . Any residual SI is handled by the  translates to 25% and 50% less taps compared to the SotA
          RX digital combiner. The combiner U used in the previ‑  requiring    = 16 taps. In addition, Figs. 4c and 4d show‑

          ous designs is used for the latter purpose.          case that the proposed multi‑AUX TX solution with    = 2
                                                               and    = 3 AUX TXs is the only one based on AUX TXs that
          6.2 Simulation parameters                            is capable of offering residual SI power below −60dBm
                                                               for all P values. Actually, the SotA design with    = 4

          We have assumed Rayleigh fading and a path loss of 110dB  AUX TXs (i.e., with 50% and 25% more AUX TXs than the
          for both the DL H   ,    and UL H   ,    channels. The SI chan‑     = 2 and    = 3 AUX TXs cases) cannot meet the resid‑
          nel H   ,    is assumed to be subject to Ricean fading with  ual constraint for P ≥ 15dBm.

            ‑factor equal to 35dB and path loss of 40dB [31]. All in‑  We now investigate in more detail how our proposed joint
          volved wireless channels are assumed to be Independent  analog cancellation and BF design adapts in order to meet
          and Identically Distributed (IID), and perfectly estimated  the constraint on residual SI, while providing spatial re‑
          at the receivers (i.e., at the RXs of nodes    and   ). We have  sources for DL and UL communications. Recall that
          used 1000 independent channel realizations for all statis‑  used in the precoder solving     3 determines the effective
          tical results. The DL transmit power P was set between  number of TX antennas used for DL data transmission. An

          10dBm and 40dBm, and the UL transmit power P     was     close to    means that the TX BF of the FD node is us‑

          set 20dB lower, hence, spanning a range from −10dBm  ing more antenna resources for improving DL than for SI
          to 20dBm [32]. The noise  loor at node    is −90dBm and  reduction. Therefore,    determines the trade‑off between
          at node    is −110dBm. The latter values are typical ones  acceptable SI levels as well as DL and UL achievable rates.
          for small cell base stations and mobile terminals. Follow‑  In Figs. 5a and 5b, we illustrate the average values of
          ing the  indings of [3], we consider a 14‑bit ADC at node  chosen by our FD MIMO design as functions of the DL and
             that renders digital SI mitigation of approximately 50dB  UL TX powers for the case of the multi‑tap architecture
          feasible. This means that for the noise  loor of −110dBm  (for    = 4 and    = 8 taps) and multi‑AUX TX architec‑
          at node    the residual SI after analog cancellation (i.e., at  ture (for    = 2 and    = 3 AUX TXs), respectively, and
          each RX RF chain’s input) must be less than −60dBm. In  for    =        = 1 and    =        = 4. From these  ig‑


          Appendix A we present the two realistic models used for  ures we observe that for a given    and    , the value of


          simulating non‑ideal analog canceler hardware. The one     increases as the number of taps (or AUX TXs) increases.
          model concernsthe proposedmulti‑tap canceler architec‑  For example, in Fig. 5a for    =        = 1, the values of

          ture and the other the multi‑AUX‑TX one. According to  for    = 8 taps are always larger than the values of    for
          these models, the multi‑tap canceler is capable of deliv‑     = 4 taps. The more the taps (or AUX TXs), the more
          ering approximately 60dB of analog cancellation per tap,  analog canceler resources are provided for SI mitigation,
          whereas the multi‑AUX‑TX canceler offers approximately  and hence, less antenna resources are required for this
          35dB of cancellation per AUX TX RF chain.            mitigationinordertomeettheresidualSIconstraint. This
                                                               is why our algorithm chooses a larger    as the number of
          6.3 Self‑interference mitigation capability          taps (or AUX TXs) increases. Thus, the results in Fig. 5
                                                               verify that our FD MIMO design is capable of judiciously
          We consider a 4 × 4 FD MIMO node    (i.e.,    =    = 4)  dividing the burden of SI mitigation between the analog


          and two different cases for the number of antennas at  canceler and the TX digital BF by taking into account the
          nodes    and   : the single‑antenna case (i.e.,    =        =  resources available for analog cancellation.

          1) and the multi‑antenna with    =        = 4. We in‑  AnotherobservationfromtheresultsinFig.5isthatasthe

          vestigate in Fig. 4 the probability that the residual SI af‑  number    of RX antennas in DL and/or the number

          ter analog cancellation meets the constraint of being less  of TX antennas in UL increase, our FD MIMO design tends
          than    A  = −60dBm. Results are shown for both pro‑  to be more conservative in the choice of    since it chooses
          posed multi‑tap and multi‑AUX TX architectures for vari‑  a smaller value for   . For example, in Fig. 5a for the case
          ous hardware complexity levels, as implicated by differ‑  of    = 8 taps, the values of    for    =        = 1 are larger

          ent values of    for the taps and AUX TXs, respectively.  than those for    =        = 4. The reason for this behav‑

          Within Fig. 4, we also sketch results for SotA designs with  ior is as follows. Recall that the number of UL streams is
             = 16 taps and with    = 4 AUX TXs, as well as for the  equal to        ≤ min{   ,    }. Since    = 4, then as



          only digital SotA solution (i.e., 0 taps or 0 AUX TXs). For  increases from 1 to 4, there will be more streams in the
          the latter design, we have one DL stream for the precoder,  UL communications. This increment of UL streams makes
          since this was the con iguration yielding the largest SI re‑  the design of TX digital BF more demanding, since it has
          duction, however, as shown from all sub igures of Fig. 4,  to steer SI away from these several incoming UL streams
